Reference Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Instruction Manual
ECO-2-A2L-e
Oil tank
Handle / exhaust port
O-ring
Pump cylinder unit
Sliding block
O-ring
O-ring
O-ring
Oil filler cap
Bracket
Motor stator subassembly
Solenoid valve
Motor rotor subassembly
Intake port
Inlet subassembly
Nut
Fan
Rear cover
Rechargeable battery adapter
Base
Control unit subassembly
Base cover plate
Start / Stop button
Label
Manual stop valve
17
