No. Component
1 Touch screen
VDI port (connector port
2 for specific Ambu
visualization devices)
3 USB 3.0 port (front)
4 USB port cover (front)
5 Power button
6 Base
7 Positioning arm
8 Power cable
9 Wi-Fi antenna
Video output ports
10
(2x DVI-D)
Video output ports
11
(2x 3G-SDI)
12 Wi-Fi antenna connector
13 USB 3.0 ports
14 LAN port
15 USB 2.0 ports
Trigger output ports
16
(2 x 3.5 mm jack)
Trigger output ports
17
(2 x D-SUB9)
18 Power inlet
Connector for potential
19
equalization cable
10
Function
Displays the graphical user interface and shows
the live image from the Ambu visualization device.
Connector port geometry and colour ensures correct
connection with compatible visualization devices.
Enables connection of external USB flash drives.
Protects the front USB port.
Turns the power ON or switches to STANDBY mode.
Contains the main unit.
Enables manual positioning of the touch screen.
The screen can be adjusted horizontally and
vertically as well as rotated.
Connects the displaying unit to a power outlet.
Connect Wi-Fi antenna to the displaying unit for
improved Wi-Fi signal.
Enable connection to external monitor or external
imaging recorder. See section 12.1 for details on the
difference between using DVI-D and 3G-SDI on the
displaying unit.
Enables connection of Wi-Fi antenna.
Enables connection of external USB flash drives.
Enables connection to ethernet.
Enables connection of external USB flash drives.
Enable connection to an external imaging recorder
to transfer trigger signals.
Enables connection to power cable.
Enables bonding of electrical products to eliminate
potential differences between conductive parts.
