• Impairment of hearing.
• Risk of personal injury due to flying particles.
• Risk of burns due to accessories becoming hot during operation.
• Risk of personal injury due to prolonged use.
SAVE THESE INSTRUCTIONS
Battery Type
These battery packs may be used:
Battery (kg)
DCB546
1.08
DCB547/G 1.46
DCB548 1.46
DCB181
0.35
DCB182 0.61
DCB183/B/G 0.40
Refer to the battery/charger manual for more information.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear eye, ear and head protection.
Do not leave in rain.
Wear protective gloves.
Wear protective footwear.
Rotational direction of the saw chain.
Beware of chain saw kickback and contact of the guide
bar tip with any object should be avoided.
Switch the tool off. Before performing any maintenance
on the tool, remove the battery from the tool.
Directive 2000/14/EC guaranteed sound power.
Do not contact the guide bar tip with any object.
Always use two hands when operating the chainsaw.
Lock and unlock the chain brake.
Date Code Position (Fig. L)
The production date code 28
by a 2-digit week and is extended by a 2-digit factory code.
Battery (kg)
DCB184/B/G
0.62
DCB185 0.35
DCB187 0.54
DCB189
0.54
DCBP518/G 0.75
consists of a 4-digit year followed
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury could result.
On/Off trigger switch
1
Lock-off lever
2
Chain brake/front hand guard
3
Guide bar
4
Saw chain
5
Sprocket cover
6
Battery Pack
7 †
Bar lock nut
8
Chain tensioning screw
9
Oil level indicator
10
Guide bar scabbard
11
Rear handle
12
Front handle
13
Battery housing
14
Battery release button
15
Oil cap
16
Wrench
17
Included in some packages.
†
nOtE: Check for damage to parts or accessories which may
have occurred during transport.
Intended Use
The DCMCS565 chainsaw is designed for cutting limbs or logs
up to 25 cm in diameter.
DO nOt use under wet conditions or in presence of flammable
liquids or gases.
These chainsaws are professional power tools.
DO nOt let children come into contact with the tool. Supervision
is required when inexperienced operators use this tool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or mental
abilities; lack of experience, knowledge or skills unless they are
supervised by a person responsible for their safety. Children
should never be left alone with this product.
• Do not store or use the tool and battery pack in locations where
the temperature may fall below 4˚ C (39˚ F) (such as outside
sheds or metal buildings in winter), or reach or exceed 40˚ C
(104˚ F) (such as outside sheds or metal buildings in summer).
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal injury,
turn tool off and disconnect battery pack before making any
adjustments or removing/installing attachments or accessories.
An accidental start-up can cause injury.
WARNING: Use only D
e

Inserting and Removing the Battery Pack from the
Tool (Fig. B, C)
nOtE: Make sure your battery pack
To Install the Battery Pack into the Tool
1. Align the battery pack 7
WALT batteries and chargers.
7 is fully charged.
with the rails inside the tool (Fig. B, C).
