WARNING
• Make sure that the push button is
always closed and located under the
mattress.
• Never use the carrycot+ if the press
stud is damaged or missing.
• Never carry the carrycot with a child
in it when the backrest is in a raised
position.
6� Extendable sun protection
(Carrycot+)
The carrycot+ is equipped with an
extendable sunshade under the front part
of the canopy.
6.1 Carefully open the zip in the front part
of the canopy. Unroll the black UV
protection.
6.2 Pull it over the foot end of the
reclining section and fasten it with 2
press studs underneath.
6.3 When the UV protection is not in use,
roll it up again and stow it back in the
front part of the canopy.
It is possible to use the sunshade at the
same time as the insect screen:
Attach the insect screen to the inside
of the soft top and then use the sun
protection over it as described above.
7) Folding the carrycot
Remove the mattress.Pull the bar using
the easy pull handle along the bottom of
the carrycot. Repeat both in the foot end
and the head end.
Seat unit (ERGO+ & FLAT)
1) Assembly of the seat unit
ERGO+
1.1 Seat Frame. Press both buttons on the
sides of the footrest to unfold.
1.2 Fold out both seat attachments.
1.3 Place the seat fabric cover over the
top edge of the seat frame.
1.4 Thread the harness strap through the
seat fabric and then place the seat
fabric around the seat plate. Close
SENTO MAX Carrycot+, ERGO+, FLAT v. 2.0
the fabric underneath the seat with
the Velcro.
1.5 Position the safety straps around the
frame and click into the buckle on the
back of the backrest. Repeat on the
left and right side of the frame.
1.6 Fasten the press studs that secure the
fabrics to the frame on both sides.
1.7 Take the straps at the bottom on the
backside of the seat unit and fasten
each one of them with the press studs
on the seat fabric according to the
picture. Make sure you click each strap
to the lowest of the press studs.
1.8 Securely attach these straps to the
seat on both sides according to the
pictures.
1.9 Ensure that both straps are securely
fastened with the press studs.
1.10 Click the back rest adjustment handle
into the bracket on both sides.
1.11 Thread the strap through the hole in
the fabric and fasten around the back
rest adjustment handle with the press
stud.
1.12 Insert the bumper bar into the
brackets on both sides of the seat
unit.
1.13 Fasten the crotch strap around the
front bar.
1.14 Attach the hood onto the seat frame
tubes at both sides.
WARNING
Pinch point - Danger of trapping.
1.15 Pull the fabric over the top of the seat
frame and secure with the lower press
stud. Repeat for the left and right
sides.
Please note:
If the hood moves up and down on
the seat frame tube this can cause
scratches. Ensure the seat frame tube
is free from dust and dirt.
