This field can impair active or passive medical im-
plants under certain conditions. In order to prevent the
risk of serious or deadly injuries, we recommend that
persons with medical implants consult with their physi-
cian and the manufacturer of the medical implant prior
to operating the electric tool.
Additional safety instructions
• Wear safety gloves whenever you carry out any
maintenance work on the blade!
• When cutting round or irregularly shaped wood, use
a device to stop the workpiece from twisting.
• When cutting boards in upright position, use a de-
vice to prevent kick-back.
• A dust extraction system designed for an air velocity
of 20 m/s should be connected in order to comply
with woodworking dust emission values and to en-
sure reliable operation.
• Give these safety regulations to all persons who
work on the machine.
• Do not use this saw to cut fire wood.
• The machine is equipped with a safety switch to
prevent it being switched on again accidentally af-
ter a power failure.
• Before you use the machine for the first time, check
that the voltage marked on the rating plate is the
same as your mains voltage.
• If you use a cable reel, the complete cable has to
be pulled off the reel.
• Persons working on the machine should not be dis-
tracted.
• Note the direction of rotation of the motor and blade.
• Never dismantle the machines safety devices or put
them out of operation.
• Never cut workpieces which are too small to hold
securely in your hand.
• Never remove loose splinters, chips or jammed
pieces of wood when the saw blade is running.
• It is imperative to observe the accident prevention
regulations in force in your area as well as all other
generally recognized rules of safety.
• Note the information published by your professional
associations.
• Adjustable protective devices have to be adjusted
as close as possible to the workpiece.
• Important! Support long workpieces (e.g. with a roll-
er table) to prevent them sagging at the end of a cut.
• Make sure the blade guard (3) is in its lower position
when the saw is being transported.
• Safety guards are not to be used to move or misuse
the machine.
• Blades that are misshapen or damaged in any way
must not be used.
• If the table insert is worn, replace it.
• Never operate the machine if either the door protecting
the blade or the detachable safety device are open.
• Ensure that the choice of blade and the selected
speed are suitable for the material to be cut.
• Do not begin cleaning the blade until it has come to
a complete standstill.
• For straight cuts of small workpieces against the
longitudinal limit stop the push stick has to be used.
• The bandsaw blade guard should be in its lowest
position close to the bench during transport.
• For miter cuts when the table is tilted, the parallel
stop must be positioned on the lower part of the table.
• When cutting round timber, use a suitable holding
device to prevent the workpiece turning.
• Never use guards to lift or transport items.
• Ensure that the bandsaw blade guards are used and
correctly adjusted.
• Keep your hands a safety distance away from the
bandsaw blade. Use a push stick for narrow cuts.
• The push stick has to be stored on the intended de-
vice, so that it can be reached from normal working
position and is always ready to be used.
• In the normal operating position the operator is in
front of the machine.
• When sawing wood, connect the band saw to a dust
collection device.
• When cutting round or irregularly shaped wood, use
a suitable holding device that prevents the work-
piece from twisting.
6. Technical data
Electro motor
Power
Revolutions
Saw band length
Saw band width
Saw band width max.
Saw band speed I
Saw band speed II
Cutting height
Opening width
Table size
Slewing range of the table
size of workpiece max.
Weight
www.scheppach.com
220 - 240 V ~, 50 Hz
550 W (S2 20 min)
1400 rpm
1790 mm
6 mm
13 mm
660 m/min
960 m/min
0 - 120 mm
245 mm
300 x 300 mm
0° - 45°
580 x 400 x 120 mm
24 kg
