4. MAP CREATION
• Place correctly the charging station in
keeping with instructions in the manual
• After that, place the vacuum cleaner onto
the charging station and wait until the
vacuum cleaner is fully charged.
1
• Make available all rooms, in which you
want to clean up regularly (open the
doors and remove all obstacles, which
could prevent the vacuum cleaner from
movement).
There are two ways to create a map:
1. By performing the initial automatic cleaning
• On the main screen, select the cleaning
type "Normal" (automatic cleaning) by
clicking on it and then start the cleaning by
clicking on "Start clean".
• The vacuum cleaner will automatically clean
2
the available space while creating a map.
2. Quick map creation function
• Go to "Settings" and select "Create map"
from the menu.
• Then confirm the choice by clicking on "OK".
• The vacuum cleaner will only map the
accessible area.
• Let the vacuum cleaner create a map in
3
the way you choose.
• Once the map is complete, you can
4
continue to work with it and make various
adjustments.
• If the map is created correctly, the map is
automatically saved. You can see this by
going to "Settings".
• Select „Map list" in menu.
• Newly created maps are automatically
named and numbered (Map1, Map2...
etc.). Click on the appropriate map to
5
continue working with the map.
• Click on "Set as current map" to set the
map as the current map.
• Click on "Rename" to change the name of
the map.
• Click on the "Trash can" symbol in the
upper right corner to delete the map.
REMARKS:
• If you have carpets in your home, we recommend NOT using the mop
attachment when creating the map. You must also turn off "Carpet
cleaning mode" (see Chapter 18. CARPET CLEANING MODE).
• In total, you can create an save up to 5 maps. This option may be
used, especially, in case of multistage houses.
5. MAP MODIFICATION AND ADAPTATION
Automatic division of the map into rooms
1
• If the map is created correctly, the
application automatically divides it into
rooms, which are distinguished by color.
Possible map modifications in menu
„Edit area"
Go to "Settings" and select "Edit area":
2
• „merge" (using this function, you can join 2
adjacent rooms);
• „segmentation" (using this function, you can
divide 1 room in 2 rooms);
• „Rename" (using this function, you can
arbitrarily name rooms).
Combining rooms
3
• Select two adjacent rooms.
• Then click on "merge".
EN
EN - 41
