ENGLISH
4. CLEANING AND MAINTENANCE
Cleaning the main brush. Fig. 9
The main brush spins at top speed and helps pushing the dirt into the suction mouth. This
brush is in contact with the floor, and therefore with dirt, so it can wear out overtime, affecting
negatively to the cleaning efficiency. For this reason, it is suggested to replace the main brush
after a maximum of 320 hours or less.
1. Slightly press the main brush frame's tabs to open the main brush compartment and
remove it.
2. Remove hair, lint, and other dirt trapped in the brush and around the shafts with the help
of the self-cleaning brush.
3. Clear and clean the robot vacuum cleaner's suction channel.
4. Reinstall the main brush and its frame.
Recommendation
It is recommended to clean the main brush once a week with the help of the self-cleaning
brush.
Side brush. Fig. 10
The side brush is designed with many bristles and used both to push dirt into the suction
mouth and thoroughly clean edges and corners. This brush may wear out overtime, which will
negatively affect cleaning efficiency.
Recommendations
It is recommended to clean the side brush once a week with the help of the self-cleaning brush.
Remove the retaining screw of the side brush with a screwdriver and clean the brush regularly.
After cleaning, reinstall the side brush using the screwdriver.
Recommendation
To ensure perfect cleaning, it is recommended to change the side brush every 3 months
(depending on frequency and type of use).
Dirt tank. Fig. 11.
1. Lift the top cover of your robot.
2. Press the tank removal button and remove the tank.
3. Use the self-cleaning brush to clean the inside of the mixed tank.
4. You can clean the dirt tank with water, without immersing the tank.
5. Reinstall the dusk tank on the robot vacuum cleaner.
Filters.
High-efficiency filter
76
CONGA 13090 SPIN REVOLUTION HOME&WASH
- The high-efficiency filter is designed with fibres that help trap dust particles, dust mites,
pollen, etc. It is very important to periodically clean the filter, to prevent these particles
from building up in the filter, causing efficiency loss. It is convenient to carry out this
maintenance once a week.
- Replace the high efficiency filter every 3 months, depending on the frequency and type of
use.
Recommendation
You can remove dirt from the high-efficiency filter with a small brush or gently shake the filter
on a hard surface to remove the dust. The high-efficiency filter cannot be washed.
Primary mesh filter and sponge filter
The filtering system is featured with a primary mesh filter and a sponge filter, located next to
the high-efficiency filter. It is suggested to replace them either after a maximum of 160 hours
of use or when they are worn out due to operation.
Recommendation
Dirt can be removed with a small brush or by shaking carefully against a hard surface for dust
to fall off. You can also use warm water without detergents to obtain better results. Always
make sure they are completely dry before installing them again; otherwise, moisture can reach
the robot vacuum cleaner's motor and damage it.
Sensor cleaning. Fig. 12:
- The robot vacuum cleaner has different types of sensors, for example, proximity sensors
that allow the robot to move around while detecting obstacles, or fall-detection sensors
that help the robot detect slopes or possible gaps/unevenness such as staircases. These
sensors are always in contact with dust particles, and therefore can deteriorate over time,
causing possible navigation errors.
- Use a clean, dry, and soft cloth to wipe off any dust from the free-fall sensor located on the
robot vacuum cleaner part.
- It is recommended to clean all sensors of the robot vacuum cleaner every 35 hours of use
or less, using a soft, dry cloth.
Mop holder. Fig. 13:
- The mop holder is attached to the robot with magnets. It is important to keep these clean
to ensure good contact.
- For cleaning, remove the mop holders and wipe the magnets with a soft, dry, clean cloth.
- Replace the holders.
Charging base. Fig. 14:
- Clean the dirty water tank and the different cleaning areas of your charger base by
removing these parts as indicated by the direction arrows.
ENGLISH
CONGA 13090 SPIN REVOLUTION HOME&WASH
77
