14 Anhang
Register Num- Register Name
ber
3602 Application solid
14.5 Messwerte (Input-Register)
Register Number Register Name
100 Status
104 PV Unit
106 PV
108 SV Unit
110 SV
112 TV Unit
114 TV
116 QV Unit
118 QV
1300 Status
1302 PV
1304 SV
1306 TV
1308 QV
54
Data type Configurable Values
enum16 0=Silo, 1= Bunker Big,
2=Bunker fast filling,
r/w
3=Profil registration heap,
4=Breaker mill, 5=De-
monstration
Data type Note
Access
enum8 Bit 0: Invalid Measurement Value PV, Bit 1: Invalid Measu-
rement Value SV, Bit 2: Invalid Measurement Value TV, Bit
ro
3: Invalid Measurement Value QV
enum16 32=Degree Celsius, 33=Degree Fahrenheit, 39=Percent,
40=US Gallons, 41=Liters, 42=Imperial Gallons, 43=Cu-
ro
bic Meters, 44=Feet, 45=Meters, 46=Barrels, 47=Inches,
48=Centimeters, 49=Millimeters, 111=Cubic Yards,
112=Cubic Feet, 113=Cubic Inches
float32 Primary Variable in Byte Order CDAB
ro
enum16 Unit Code
ro
float32 Secondary Variable in Byte Order CDAB
ro
enum16 Unit Code
ro
float32 Third Variable in Byte Order CDAB
ro
enum16 Unit Code
ro
float32 Quarternary Variable in Byte Order CDAB
ro
enum8 See Register 100
ro
float32 Primary Variable in Byte Order of Register 3000
ro
float32 Secondary Variable in Byte Order of Register 3000
ro
float32 Third Variable in Byte Order of Register 3000
ro
float32 Quarternary Variable in Byte Order of Register 3000
ro
VEGAPULS C 21 • Modbus- und Levelmaster-Protokoll
Unit Default Value
- Silo
