4.3
Product dimensions and connection
dimensions
3 6
0
180
81.5
0020166669_06 Installation instructions
0
2 5
180
87
101
40
40
81.5
4.4
Clearance from combustible components
▶
Ensure that no highly flammable parts come into contact
with the components as these may reach temperatures of
over 80 °C.
▶
Ensure that there is a minimum clearance between the
highly flammable parts and the hot components.
–
Minimum clearance: 200 mm
4.5
Minimum clearances
20
min.
min.
* Free space required for installing or maintaining the
product.
▶
Comply with the clearances that are shown in the plan.
▶
Ensure that the water-supply connections can be ac-
cessed for checks.
▶
Provide sufficient clearance on both sides of the product
in order to facilitate access for maintenance and repair
work.
4.6
Observing the requirements for the
product's installation site
▶
Ensure that the room in which the product is installed is
not heated to the maximum recommended room temper-
ature.
–
Permissible room temperature: 30 ℃
▶
Do not install the product above another unit that may
damage it (e.g. above a cooker that produces water va-
pour and grease) or in a room with a high level of expos-
ure to dust or in a corrosive environment.
▶
Do not install the product below a unit from which liquids
may flow.
▶
Ensure that the room in which you want to set up the
product is sufficiently protected against frost.
20
>600*
21
