3.3 Data plate
The data plate (1) is located on to the right of the plate heat
exchanger.
3.3.1 Information on the data plate
The data plate keeps record of the country in which the
product is to be installed.
Information on the data
plate
Country code "XX"
Serial no.
Code
PMS
V
Hz
A
W
IP
20
Meaning
Country in which you want to
install the product
Trade name and serial num-
ber for the product
Product code for the product
Permissible total excess
pressure in heating mode
Mains voltage
Mains frequency
Amperage
Power consumption
IP rating
3.4 CE marking
The CE marking shows that the products comply with the
basic requirements of the applicable directives as stated on
the declaration of conformity.
The declaration of conformity can be viewed at the manufac-
turer's site.
3.5 UKCA mark
Validity: Great Britain
1
The UKCA marking shows that the products comply with
the basic requirements of the applicable directives as
stated on the declaration of conformity.
The declaration of conformity can be viewed at the manu-
facturer's site.
4 Installation
All dimensions in the figures are specified in millimetres
(mm).
4.1 Unpacking the product
1. Remove the product from the packaging.
2. Remove the protective film from all of the product's
components.
4.2 Checking the scope of delivery
▶
Check that the scope of delivery is complete.
Quantity Designation
1 Decoupler module
1 Bag with accessories
–
–
–
1 Enclosed documentation
Retainer for suspension (x1)
1" flat seal (x6)
Flat seal 1 1/4" (x2)
