Bestellinformationen Levelflex M FMP45
10 Zulassung:
A Ex-freier Bereich
F Ex-freier Bereich, WHG
1 ATEX II 1/2G EEx ia IIC T6/IECEx Zone 0/1
2 ATEX II 1/2D, Alu Blinddeckel
3 ATEX II 1/2G EEx em [ia] IIC T6/IECEx Zone 0/1
4 ATEX II 1/3D
5 ATEX II 1/2G EEx ia IIC T6, ATEX II 1/3D
6 ATEX II 1/2G EEx ia IIC T6, WHG
7 ATEX II 1/2G EEx d [ia] IIC T6
8 ATEX II 1/2G EEx ia IIC T6, ATEX II 1/3D, WHG
G ATEX II 3G EEx nA II T6
M FM DIP Cl.II Div.1 Gr.E-G N.I.
S FM IS Cl.I,II,III Div.1 Gr.A-G N.I.
T FM XP Cl.I,II,III Div.1 Gr.A-G
N CSA General Purpose
P CSA DIP Cl.II Div.1 Gr.G + coal dust, N.I.
U CSA IS Cl.I,II,III Div.1 Gr.A-D, G+coal dust, N.I.
V CSA XP Cl.I,II,III Div.1 Gr.A-D, G+coal dust, N.I.
K TIIS EEx ia IIC T4
L TIIS EEx d [ia] IIC T5
Y Sonderausführung
20 Prozesstemperatur:
A -200...+280 °C (XT)
B -200...+400 °C (HT)
Y Sonderausführung
30 Sonde:
A .....mm, Seil 4mm, 316
C .....inch, Seil 1/16", 316
K .....mm, Stab 16 mm, 316L
L .....mm, Koax, 316L
M .....inch, Stab 16 mm, 316L
N .....inch, Koax, 316L
Y Sonderausführung
40 Prozessanschluss:
AFJ 2" 150lbs RF, 316/316L Flansch ANSI B16.5
AGJ 3" 150lbs RF, 316/316L Flansch ANSI B16.5
AHJ 4" 150lbs RF, 316/316L Flansch ANSI B16.5
ARJ 2" 300/600lbs RF, 316/316L Flansch ANSI B16.5
ASJ 3" 300/600lbs RF, 316/316L Flansch ANSI B16.5
ATJ 4" 300lbs RF, 316/316L Flansch ANSI B16.5
A1J 2" 1500lbs RF, 316/316L Flansch ANSI B16.5
A2J 3" 1500lbs RF, 316/316L Flansch ANSI B16.5
A3J 4" 600lbs RF, 316/316L Flansch ANSI B16.5
A4J 4" 900lbs RF, 316/316L Flansch ANSI B16.5
A5J 4" 1500lbs RF, 316/316L Flansch ANSI B16.5
CHJ DN100 PN10/16 B1, 316L Flansch EN1092-1 (DIN2527 C)
CRJ DN50 PN10-40 B1, 316L Flansch EN1092-1 (DIN2527 C)
CSJ DN80 PN10-40 B1, 316L Flansch EN1092-1 (DIN2527 C)
CTJ DN100 PN25/40 B1, 316L Flansch EN1092-1 (DIN2527 C)
C1J DN50 PN63 B2, 316L Flansch EN1092-1 (DIN2527 E)
C2J DN50 PN100 B2, 316L Flansch EN1092-1 (DIN2527 E)
C3J DN80 PN63 B2, 316L Flansch EN1092-1 (DIN2527 E)
C4J DN80 PN100 B2, 316L Flansch EN1092-1 (DIN2527 E)
C5J DN100 PN63 B2, 316L Flansch EN1092-1 (DIN2527 E)
C6J DN100 PN100 B2, 316L Flansch EN1092-1 (DIN2527 E)
KFJ 10K 50 RF, 316L Flansch JIS B2220
KGJ 10K 80 RF, 316L Flansch JIS B2220
KHJ 10K 100 RF, 316L Flansch JIS B2220
K3J 63K 50 RF, 316L Flansch JIS B2220
K4J 63K 80 RF, 316L Flansch JIS B2220
K5J 63K 100 RF, 316L Flansch JIS B2220
FMP45- Produktbezeichnung (Teil 1)
Levelflex M
