4. Place the disc lid (14) on the bowl (8) as shown on Fig. 7, press it and turn it so that the handles
of the bowl and the lid are aligned with each other (the lid's tabs fit into the bowl sockets).
5. Place the pusher (13) in the disc's lid.
6. Follow the steps to remove the disc from the device:
- slightly turn the lid (14) anti-clockwise so that the lid's tabs slide out of the bowl sockets and
gently remove the lid
- remove the bowl from the food processor's base
- remove the disc (16) from the pin (17)
- remove the pin (17) from the shaft (24).
ASSEMBLY/DISASSEMBLY OF THE DICING ATTACHMENT
1. Follow the steps in Point 1-3 in the chapter MOUNTING / REMOVING THE BOWL.
2. Fit the dicing insert (28) in the dicing attachment (26). Then fit the attachment knife (27) with
the blade upwards and lock the locking clamps (29).
3. As shown in the figure below, fit the disc mounting pin (17) into the bowl, then insert the dicing
attachment (26) so that the dicing insert (28) is facing the handle of the bowl.
1
3
4. Place the disc lid (14) on the bowl (14), press it and turn it so that the handles of the bowl and
the lid are aligned with each other (the lid's tabs fit into the bowl sockets).
5. Place the pusher (13) in the disc's lid.
6. In order to remove the dicing attachment from the appliance, take the following steps:
- slightly turn the lid (14) anti-clockwise so that the lid's tabs slide out of the bowl sockets and
gently remove the lid
- remove the bowl from the food processor's base
- Remove the dicing attachment (26) by grasping the two holes in the attachment paying
attention to the sharp edges of the knife and then remove the disc mounting mandrel.
CAUTION! The knife's blades are very sharp. Handle them with extreme care.
2
4
