MPM iCoook 3.0 PLUS Bedienungsanleitung Seite 31

EN
ROBOT'S ACCESSORIES AND FEATURES
CONTROL PANEL WITH
TOUCH-SCREEN
– the control
panel uses a 10" touch-screen. The
robot can be used with dedicated
recipes stored in its data base and
automatic programs for using its ac-
cessories. Settings can be also cus-
tomized. The recipe data base can
be updated via the Wi-Fi module.
The bowl and lid are equipped with
a system of interlocks and safety
devices to prevent start-up in case
of incorrect installation.
VIBRATION REDUCTION SYSTEM – an innovative flexible bowl
mounting system in the food processor reduces vibrations transmitted
to the food processor housing during high speeds or heavy pulp knead-
ing.
BOWL AND BOWL LID – bowls (8) are made of high-grade stainless
steel. There is an opening for mounting the drive shaft (24) in each bowl's
bottom. There are six horizontal lines on the inner wall of the bowl, de-
noting the following capacities - 600 ml, 1000 ml, 1500 ml, 2000 ml and
2500 ml, and MAX capacity (3000 ml). Each bowl is equipped with han-
dles for easy adjustment. The lid of the bowl (2) is fitted with a seal to
ensure that it is leakproof during use. The tilting lid cap (1) allows dosing
of ingredients and spices. The bowl and lid are equipped with a system of
interlocks and safety devices to prevent activation in case of incorrect installation.
KNIFE – the knife blades (6) are made of stainless steel selected to retain their
parameters for a very long service life. Its unique design provides the highest
performance, even at the lowest speed setting.
STIRRER – the shape of the stirrer (5) has been designed so that the content
of the bowl is only mixed, without shredding. It is suitable for slow and long
cooking of, e.g. soups. The stirrer has different mixing characteristics de-
pending on the direction of rotation.
CAUTION! Do not set the speed higher than "3" when working with the mixer.
LIGHTWEIGHT PULP (BUTTERFLY) STIRRER – the butterfly stirrer (4)
allows whisking light creams, pulps and as well as egg whites. The design
prevents the whisked pulp from being completely shredded.
CAUTION! Do not set the speed higher than "4" when working with the butterfly mixer.
GRATING / SLICING DISC – the disc (16) is used for gratin and slicing fruit and vegeta-
bles. The function of the disc depends on the side of its mounting. The pow-
er to the disc is transferred via the pin (17).
33
