EN
MOUNTING / REMOVING THE BOWL
CAUTION! Never start an incomplete device. Risk of injury!
1. Make sure the seal is seated correctly on the drive shaft (24).
2. Insert the drive shaft (24) inside the bowl so that its gear goes through the hole in the bottom
and then lock the shaft by turning the locking mechanism (25) clockwise outwards (fig.1)
3. Place the bowl (8) on the device's housing (11) so that the volume markings inside the bowl are
at the device's back (Fig 2).
4. Place one of the accessories on the installed shaft (24) (Fig. 3):
- light product stirrer - butterfly (4)
- stirrer (5)
- knife (6)
- strainer (7)
CAUTION! The knife's blades are sharp. Handle them with extreme care!
5. Make sure the seal (3) is correctly seated in the bowl lid (2). It must be correctly seated all round
with the thicker side against the protruding rim inside the lid.
6. Place the bowl lid (2) on the bowl (8) as shown on Fig. 4, press it and turn it so that the handles
of the bowl and the lid are aligned with each other (the lid's tabs fit into the bowl sockets).
7. Follow the steps to remove the bowl from the device:
- slightly turn the lid (2) anti-clockwise so that the lid's tabs slide out of the bowl sockets and
gently remove the lid
- remove the bowl from the food processor's base
- remove the accessory from the shaft (butterfly, stirrer, knife), you can use the spatula for
this purpose
- Take out the basket using the handle or the spatula (fig.5).
MOUNTING / REMOVING THE STEAM COOKING BOWL
1. Follow the steps in Point 1-3 in the chapter MOUNTING / REMOVING THE BOWL.
2. Make sure the seal (23) is correctly seated in the steam cooking bowl (22). The entire circumfer-
ence of the seal must be in contact with the external part of the ring inside the bowl.
3. Place the steam cooking bowl (22) on the bowl (8) as shown on Fig. 6, press it and turn it so
that the handles of the two bowls are aligned with each other (the bowl tabs fit into the bowl
sockets). Place the tray (21) on the bowl (22) i close it with a lid (20).
4. Follow the steps to remove the steam cooking bowl from the device:
- remove the lid (20) and the tray (21)
- slightly turn the bowl (22) anti-clockwise so that the bowl tabs slide out of the bowl sockets
and gently remove the bowl
- remove the bowl from the food processor's base
MOUNTING / REMOVING THE GRATING / SLICING DISC
1. Follow the steps in Point 1-3 in the chapter MOUNTING / REMOVING THE BOWL. Mount
the disc fitting pin (17) on the drive shaft (24).
2. Place the grating / slicing disc (16) on the pin (17), with the side of the disc you intend to use
facing up (grating or slicing).
3. Make sure the seal (15) is correctly seated in the disc's cover (14). The entire circumference of
the seal must be inserted in the groove.
