6.1 Wiring Diagram:
Digital Outputs:
Braking control
Main contactor control inverted
Digital Inputs:
Control release
Reset
Direction of travel foward
Direction of travel reverse
Control mode
Secondary drive active
Secondary drive setpoint input
Contactor control
Setpoint selection
(only with LF.2 = 2)
Re-levelling,
Positioning,
Rated max. speed,
Inspection speed,
Inspection speed 1,
Inspection speed 2,
With binary coded setpoint selection
(LF.2 = 1), terminal assignment see
page GB 24 - GB 25
Control Terminal X2 and I/O-Expander X3
X2.8
X2.9
X2.1
X2.2
X2.3
X2.4
X2.5
X2.6
X2.7
X3.1
V X3.2
B
V X3.3
E
V X3.4
N
V X3.5
I
V X3.6
1
V X3.7
2
6. Connection
Relay Outputs:
X3.15 Braking control
X3.16 Relay contact
X3.18 Positioning speed
X3.19 Relay contact
X3.20 Main contactor control
X3.21 Relay contact
X2.20 Heat sink temperature> LF.66
Heat sink temperature < LF.66
X2.21
(5 K hysteresis)
X2.22 Relay contact
X3.13 Ready
X3.14 Operating frequency warning
X3.17 Deceleration control
DC-monitoring
X3.22
X3.23 Motor temperature warning
Supply
X3.9 +24V (I/O-card)
X3.10 +24V (I/O-card)
X2.23 +24V (control card)
X2.11 Ground (GND)
Ground (GND)
X3.11
X3.12 Ground (GND)
