Settings menu, Fig. 14
Underfloor heating*, Underfloor heating. Turn the underfloor heating on or off.
Select continuous operation of the underfloor heating by activating "Continuous".
Engine pre-heat*. Heat the engine using the Alde heating system. Start or turn
off the function, select the start time and the engine heating duration.
Settings menu, Fig. 15
Pump in constant operation.
(Only Alde Compact 3030/3030 Plus 1-zone system)
EisEx, defroster for gas regulator. Prevents ice formation in the regulator during
winter. Select on or off, and select whether EisEx should automatically turn on
when it is cold. Automatic switch-on requires an outdoor sensor to be installed.
Delayed start, automatic boiler start.
Start or turn off the feature, select start and end time. For the function to work,
the boiler must be switched off.
External start. The function is used when starting the boiler from outside. When
external startup is enabled, the panel should be turned off. External start has
three modes: Off, External start and 230 V.
Off. The function is turned off.
External start*. The function is used when starting the boiler with external start,
by switching the "Ext Start" connector on the boiler's circuit board.
When the External Start function is activated, the control panel should be turned
off but 12 V is connected.
230 V. The function is used to start the boiler by connecting 230 V to the vehicle.
When the 230 V function is activated, the control panel should be switched off
but 12 V connected. Some vehicles may be equipped with their own solution
(winter coupling*).
Temp sensor calib, offset for temperature sensor. The temperature can be
adjusted ± 5 °C if you feel the temperature sensor needs adjusting. Also applies
to outdoor temperature sensor.
Settings menu, Fig. 16
Display. Select panel brightness: Low, Medium, or High.
You can also choose whether the status screen should be Normal, Inverted, or
Dark. If Dark is selected, the panel will go dark after 30 seconds and will light up
again if touched.
Sound. Start or turn off button and warning/notification sounds.
Language. Change the language in the Control Panel menus; available languag-
es are: English, German, and French.
Service. Displays values from the heating system; these are updated contin-
uously and describe the current status of the boiler. See section 11 Service
Menu & Reset.
System configuration, enable installed accessories and features. Here, you will find
all accessories or functions that can be connected to the Alde Heating System;
tick the features that are installed in the heating system to enable their use.
Reset. Resets the panel to factory setting. The accessories/features selected
under System Configuration are not affected.
Fig. 15.
Settings menu
Fig. 16.
Settings menu
