2. Introduction
Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling
• Non-compliance of the operating instructions
• Repairs by third parties, by not authorized service
technicians
• Installation and replacement of non-original spare
parts
• Application other than specified
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu-
lations and VDE regulations 0100, DIN 57113 /
VDE0113
Please observe the following:
Read through the complete text in the operating instruc-
tions before installing and commissioning the device.
The operating instructions are intended to help the
user to become familiar with the machine and take
advantage of its application possibilities in accord-
ance with the recommendations.
The operating instructions contain important informa-
tion on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, cost-
ly repairs, reduce downtimes and how to increase
reliability and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regu-
lations that apply for the operation of the machine in
your country.
Keep the operating instructions package with the
machine at all times and store it in a plastic cover to
protect it from dirt and moisture. Read the instruction
manual each time before operating the machine and
carefully follow its information. The machine can only
be operated by persons who were instructed con-
cerning the operation of the machine and who are in-
formed about the associated dangers. The minimum
age requirement must be complied with.
26 | GB
www.scheppach.com / service@scheppach.com / +800 4002 4002
In addition to the safety instructions contained in this
operating manual and the specific regulations of your
country, the technical rules generally accepted for the
operation of machines of the same type must be ob-
served.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
3. Device description
1.
Saw table
2. Saw blade guard
3. Riving knife (not shown)
4.
Saw blade (not shown)
5. Table inlay
6. Locking handle
7.
Scale
8. Hand wheel
9.
Crank
10. Machine stand
11. On/off switch
12. Eccentric lever
13. Parallel stop with knurled nut (i)
14. Guide rail
15. Suction adapter
16. Push stick
17. Bracket for saw blade storage
18. Legs
19a. Central strut A (2x)
19b. Central strut B (2x)
20. Rubber feet (4x)
21. Stand bracket (2x)
22. Fastening points
23. Table inlay countersunk head screws
24. Riving knife fixing screw
25. Screw with nut and washer
26a. Groove
26b. Groove
27. Knurled screw
28. Stop rail
29. Transverse stop with knurled nut (i)
30. Sight glass
30a. Screw on the sight glass
4. Scope of delivery
• Saw table with pre-mounted saw blade, 24 teeth
• Saw blade guard
• Riving knife
• Parallel stop
• Stop rail
• Transverse stop
• Push stick
• Legs (4x)
• Centre struts (4x)
• Rubber feet (4x)
• Stand bracket (2x)
