Other safety and working instructions
WARNING
• Avoid abnormal posture. Make sure that you have
secure footing and always maintain your balance.
• Using protective equipment. Always wear safety
goggles when working with the machine. Protective
clothing such as a dust protection mask, protective
gloves, sturdy and non-slip footwear and hearing
protection are absolutely necessary.
• Dust generated when working is often harmful to
health and must not get into the body. Use dust extrac-
tion and also wear a suitable dust protection mask.
Thoroughly remove deposited dust, e.g. vacuum up.
• Always keep the connection cable away from the
machine's operating area. Always lead the cable
backwards away from the machine.
• Materials that pose a health hazard (e.g. asbestos)
must not be processed.
• Pay attention to electrical cables, gas and water
lines when working in walls, ceilings or floors.
• Please switch off the device immediately when the
insertion tool is blocked! Do not switch the device on
again while the tool attachment is blocked; this could
result in a kick-back with a high torque reaction. De-
termine and remedy the cause of the insertion tool
blockage, taking the safety instructions into account.
Possible causes for this can be:
• Jamming of the workpiece to be machined
• Breaking through the material to be processed
• Overloading of the electrical tool
• Do not reach into the machine while it is running.
• Chips or fragments must not be removed while the
machine is running.
WARNING! Danger of burning
The tool attachment can become hot during use.
• During a tool change
• When putting the device down
Warning! This electric tool generates an electromag-
netic field during operation. This field can impair active
or passive medical implants under certain conditions.
In order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the electric tool.
22 | GB
6. Technical data
Stroke rate
Dimensions
L x W x H
Impact force
Weight
Motor V/Hz:
Rated input P1
Protection class:
Protection category:
Retainer:
Technical changes reserved!
Noise and vibration
The noise and vibration levels have been determined
in accordance with EN 62841.
Sound pressure level L
Uncertainty K
Sound power level L
Uncertainty K
Wear hearing protection.
Excessive noise can result in a loss of hearing.
Total vibration emission values (vector sum of three di-
rections) determined according to EN 62841.
Chisel
Main handle:
Vibration emission value
a = 26.48 m/s
h, Cheq
Uncertainty KPA = 1.5 m/s
Additional handle:
Vibration emission value
a = 18.13 m/s
h, Cheq
Uncertainty KPA = 1.5 m/s
www.scheppach.com
652 x 157 x 276 mm
230-240 V~ 50 Hz
SDS-HEX System 30 mm
pA
pA
WA (guaranteed)
WA
2
2
2
2
2000 bpm
50 Joule
16 kg
1700 W
II
IP20
95.23 dB
3.0 dB
105 dB
1.5 dB
