Bores and cabinet cutouts for input unit

To install the input unit, first 3 holes with M4 thread must be drilled according to Figure 31 respectively. Two screw connection
options have been given. They are shown in Figure 31 as I and II. Depending on the installation position, the keypad has to be
rotated according to Table 11, if necessary.
In addition to that, another cutout is required in the cabinet door, used as cable passage for the connecting cable (12) between
lock (1) and input unit (8 + 11). The size of the cable passage hole must not be more than 100 mm
diameter), and the hole must be positioned within the area of Figures 32.
Installation position

Table 11: Installation position input unit

Figure 31: Holes in operating unit and possible range for cable passage

Version 02/15/2016
Page 30 of 40
Figure Rotation
32 Not required
32 90° clockwise
32 90° counterclockwise
32 180°
I
II
Mounting instructions 82132/3xxx CB 30
2
(e.g. a hole max. 11.25 in
Possible range for cable
2
cutout <100 mm
