4.1 Preparation for installation

• Place the machine on an even and stable surface.
• Never place the machine on hot surfaces.

4.2 Electrical connection

• Make sure that the local main supply voltage corresponds to the information given on the type
plate on the front panel of the espresso machine.
• Plug the machine into a grounded socket only and do not leave it unattended.
• Do not roll or bend the power cord.
• Do not use an extension cord/ do not use a multiple socket.

4.3 Water supply connection

Important
Make sure that the fixed water connection of your machine is connected to a potable water supply
having an operating pressure ranging between 0 and 1.5 bars. We recommend to use a pressure
regulator and a shut-off valve in case the operating pressure exceeds 1.5 bars or frequently fluctuates.
The shut-off valve should be easily accessible, so that the water flow may be interrupted at any time.
Machine in use with direct water connection
The water connecting hose is to be connected to the water supply adapter (image 1).
When using the machine with direct water supply, the valve has to be turned to the side of the water supply adapter
(image 1). The water supply adapter is located in the rear part of the bottom panel (image 1). Additionally, place the
switch behind the drip tray into position "1" (image 2). Please make sure that your water tap is always open during
water-connection usage so that the machine never runs out of water!
Position "0": water tank
image 1
Important
Do not leave the machine connected when not in use.
Make sure to close the lock valve of the water connection and to switch off the electric main switch or
to disconnect the power plug when the machine is not in use.
Instruction manual MECHANIKA · TECHNIKA
Valve in position for
machine with direct water connection
(facing towards the back side of the
machine)
Place switch into position "1" for
direct water connection
Water supply adapter
24
Position "1": direct water connection
image 2
