When using a power supply with remote sensing function
Line driver
SIG
SIG
*SIG
AM26C31
Outputs: A/B phase
Point a
+
V
+
S
−S
0 V
When using a power supply without remote sensing function
Line driver
SIG
SIG
*SIG
AM26C31
Outputs: A/B phase
+
*
V
+
S
−S
0 V
When using DG10BNM/DG10BPM/DG10BSM/DG25BNM/DG25BPM/
*
DG25BLM/DG25BSM, the main unit input should be at
14
(E)
50 m or less
AWG26 or thicker
twisted pair cable
30 m or less
AWG20 or thicker
twisted pair cable
AWG20 or more
Receiving device
Line receiver:
AM26C32 or
equivalent product
120
AM26C32
+
V
+
S
−S
0 V
Receiving device
Line receiver:
AM26C32 or
equivalent product
120
AM26C32
+
V
0 V
±
+
5 V 5%.
DG10B/DG25B Series
