6. Interpolation Box

Probe resolution and directivity are set with the switches inside the interpolation box.

6-1. Resolution and Directivity Setting Method

1
Cover Removal
Remove the two screws and remove the cover.
2
Switch Setting
Output connector
Note
Do not touch any parts other than the S2 switch when changing the switch setting.
8
(E)
S2 switch (for switching resolution and directivity)
DG10B/DG25B Series
