3
Operation
Pos. Symbol Explanation
4 Timer display
Infographic: timer On/Off
Infographic: weekdays active
Infographic: day
Infographic: week
Table 17 Symbols in the display
3.4 Remote control overview
Keys on remote control
 Fig. 5
Pos. Key Function
K
1 Switch on/off.
Mode Set operating mode.
2 SET Select advanced operating functions.
OK Confirm choice.
Set timer.
.
Increase temperature.
/
Reduce temperature.
3 Fan step
Indirect airflow is active (Wind avoid me).
Turbo Turbo cool/Turbo heat
LED Switch display of indoor unit and alarm buzzer on and
off (Mute Mode).
Table 18 Keys on remote control
Display of remote control
 Fig. 6
Pos. Symbol Explanation
1 Operating function: Follow Me function is active
(Follow Me); temperature measurement at the
remote control.
Infographic: wireless control function
Infographic: battery status
2 Operating mode: automatic mode
Operating mode: cooling mode
Operating mode: dehumidification mode
Operating mode: heating mode
Operating mode: Fan Mode
3 Value display: shows the set temperature, fan speed
or (when timer is activated) the timer setting as
standard.
Infographic: transmission indicator; lights up when
the remote control sends a signal to the indoor unit.
Infographic: ON/OFF timer active.
Value display: shows the current fan speed. There are
several output stages (bars) and the AUTO setting for
automatic control
4 Infographic: Turbo cool/Turbo heat is active.
Table 19 Symbols in the display
14
3.4.1 Using the remote control
The signal range is 8 m. If objects are in the way or certain fluorescent
lamps are used in the same room this can affect transmission of the
signal.
▶ Point the remote control towards the signal receiver window of the
device and press the desired key.
The device emits a beep when it receives a signal.
NOTICE
The remote control may be permanently prevented from working
correctly.
▶ Do not expose the remote control to direct sunlight.
▶ Do not leave the remote control near a heating appliance.
▶ Protect the remote control from moisture and impacts.
3.5 Setting the day and time
▶ Press the TIMER key until the timer display starts flashing.
▶ Select the current day with the . and / keys. The selected day
flashes.
▶ Press the TIMER or  key to confirm the entry.
The selection jumps to the time.
▶ Press or hold the . or / key to set the time.
▶ Press the TIMER or  key to confirm the entry.
To toggle between 12- and 24-hour display:
▶ Press/keep the TIMER and DAY OFF keys pressed simultaneously
for several seconds.
3.6 Setting main operating mode
Depending on the indoor unit and configuration of the wired room
controller, not all operating modes may be available.
Switching the appliance on/off
▶ Press the K key to switch the device on or off:
The unit starts in the set operating mode or switches off. To protect
the unit it can only be switched back on after some time has passed.
Settings can also be made when the appliance is switched off. The
device saves the settings, and also retains them in the event of a power
failure.
After it has been switched off, the unit remains in standby mode.
Following a power failure the unit restarts automatically. This can lead to
conflicting readings on the displays which are resolved automatically
during operation.
Automatic mode
In automatic mode, the unit switches automatically between heating,
cooling, fan and dehumidification mode, depending on the set
temperature.
▶ Press the M key repeatedly until
▶ Press the . or / key to set the required temperature.
The fan speed cannot be adjusted in automatic mode.
Logacool AC166i MS – 6721849825 (2024/06)
appears on the display.
