Read installation and operating instructions in their
entirety before installing the fitting
Installation, initial operation, operation and main-
tenance must only be carried out by qualified tra-
desmen
The installation and operating instructions, as well
as other valid documents must remain with the
user of the system
Content
1. General information ....................................... 7
2. Safety notes ....................................................8
3. Transport, storage and packaging................. 8
4. Technical data .................................................8
5. Construction and function ............................. 9
6. Installation...................................................... 9
7. Operation ..................................................... 10
8. Accessories.................................................. 11
9. Maintenance ................................................ 11
10. Warranty....................................................... 11
11. Charts ......................................................... 11
Illustr. 1 "Multiblock T-RTL"
Illustr. 2 Design cover
For an overview of our global presence visit
www.oventrop.com.
Installation and operating instructions for the specialised installer
1 General information
1.1 Information regarding installation and opera-
ting instructions
These installation and operating instructions serve
the installer to install the fitting professionally and to
put it into operation.
Other valid documents – manuals of all system com-
ponents as well as valid technical rules – must be ob-
served.
1.2 Keeping of documents
These installation and operating instructions should
be kept by the user of the system.
1.3 Copyright
The installation and operating instructions are copy-
righted.
1.4 Symbol explanation
Safety guidelines are displayed by symbols. These
guidelines are to be observed to avoid accidents, da-
mage to property and malfunctions.
DANGER
nent dangerous situation which will lead to death or
serious injury if the safety guidelines are not obser-
ved.
WARNING
sible dangerous situation which may lead to death or
serious injury if the safety guidelines are not obser-
ved.
CAUTION
ble dangerous situation which may lead to minor or
moderate injury if the safety guidelines are not obser-
ved.
Subject to technical modification without notice.
Valves, controls + systems
"Multiblock T-RTL" Fitting
DANGER indicates an immi-
WARNING indicates a pos-
CAUTION indicates a possi-
