oventrop Multiblock T-RTL Einbau- Und Betriebsanleitung Seite 12

Pressure loss chart, thermostatic valve + RTL
Thermostatic valve at 2K P-deviation
Return temperature limiter at 2K up to 4K P-deviation
Pipework length: Heating circuit 33 m
Pipe material: Composition pipe "Copipe" 16 x 2 mm
Presetting
Performance data
P-deviation
Presetting 1 2
kv 0.35 0.39 0.42 0.47 0.53 0.61 0.66 0.77 0.83
Pressure loss chart, RTL (surface circuit)
Thermostatic valve at 2K P-deviation
Pipework length: Heating circuit 33 m
Pipe material: Composition pipe "Copipe" 16 x 2 mm
12
Flow rate V ˙ [l/s]
2 K
3 4 5 6 7 8
Flow rate V ˙ [l/s]
Pressure loss chart, thermostatic valve + RTL
Thermostatic valve at 2K P-deviation
Return temperature limiter at 2K up to 4K P-deviation
Pipework length: Heating circuit 100 m
Pipe material: Composition pipe "Copipe" 16 x 2 mm
Presetting
Performance data
P-deviation
9 Presetting 1
kv 0.31 0.34 0.39 0.44 0.48 0.54 0.62 0.74 0.77
Pressure loss chart, RTL (surface circuit)
Thermostatic valve at 2K P-deviation
Pipework length: Heating circuit 100 m
Pipe material: Composition pipe "Copipe" 16 x 2 mm
Flow rate V ˙ [l/s]
2 K
2 3 4 5 6 7
Flow rate V ˙ [l/s]
8 9
