1 Bag with spare parts:
1 Sealant ring on shut-off valve
(22 .5 mm)**
1 Spring gasket on shut-off valve
(12 mm)**
1 Sealant ring inside the nut of shut-off
valve (19 mm)**
1 Sealant ring inside the mist nozzle
(19 .5 mm)**
1 Sealant ring inside the fan nozzle
(16 mm)**
1 Sealant ring inside the cone spray
head (9 .3 mm)**
3 Sealant rings on plastic nozzle
pipe and stainless steel nozzle pipe
(14 .2 mm)**
1 Instruction manual
˜ Parts description
Fig. A:
1 ] [
Handle
[ 2 ]
Hose
[ 3 ]
Spray tank
[ 4 ]
Volume scale
5 ] [
Battery compartment cover
[ 6 ]
Shoulder strap
6a ] [
Strap hook
7 ] [
Spray tank pin
8 ] [
Spray tank cover
[ 9 ]
Stainless steel nozzle pipe
[ 10 ]
Plastic nozzle pipe
[ 11 ]
Hanging hook
[ 12 ]
Nozzle accessories:
Fan nozzle
Double head nozzle
Single head nozzle
Mist nozzle
Fig. B:
13 ] [
Pressure display
14 ] [
Power button
15 ] [
Charge level indicator
16 ] [
Pressure selection button
[ 17 ]
Connection status LED
Fig. C:
18 ] [
Battery pack*
19 ] [
Release button
20 ] [
21 ] [
Battery level indicator
22 ] [
Power cord with power plug
23 ] [
Battery charger (rapid battery charger)*
24 ] [
Charging control LED – red
[ 25 ]
Charging control LED – green
Fig. E to P:
26 ] [
Basket filter
27 ] [
Eyelets
28 ] [
Trigger
29 ] [
Union nut
30 ] [
Security ring
[ 31 ]
O-Ring
32 ] [
Pipe nut
[ 33 ]
Cone spray head
×4
[ 34 ]
Battery connector
[ 35 ]
Lock-on latch
[ 36 ]
Small filter
[ 37 ]
Shut-off valve
* Battery pack and rapid battery charger are
not included .
** Outer diameter
×1
×1
×1
×1
button (charging level)
×4
×2
×2
×2
