SM
Factory settings
The parameter settings are pre-adjusted at the factory. The settings should not be changed
unless necessary.
c.16.2.
Manual activation of defrosting cycle
Press UP for 5 seconds to manually activate the defrosting cycle.
If defrosting conditions are not present (for example the evaporator probe temperature is
higher than the defrost stop temperature), the display will blink three (3) times to indicate
that the operation will not be performed.
Diagnostics
The alarm condition is always signaled by the buzzer (if present) and by the LED of the
alarm icon.
• The alarm signal produced by a faulty thermostat probe (probe 1) is shown as E1
on the instrument display.
• The alarm signal produced by a faulty evaporator probe (probe 2) is shown as E2
on the instrument display.
c.16.3.
LED
Position
Related function
Compressor or
relay 1
Defrost
Alarm
c.1. Automatic defrosting
Defrosting is controlled by a separate defrosting timer containing a limiter thermostat.
Defrosting lasts approximately 30 minutes and normally takes place automatically 1-4 times
a day, depending on the cabinet model. The temperature inside the cabinet rises by a few
degrees during defrosting and the evaporation fans stop.
NOTE
SL1 cabinet does not need to be defrosted, if it is emptied and turned off for
the night.
The drain water from defrosting travels through a pipe to the sewage drain or is transferred to
the sewage drain by a separate pump. Although defrosting is automatic, the cabinet can also be
manually set to defrost. Contact your nearest servicing organisation if you need assistance with
defrosting and cleaning.
Version 04/2024
Status
ON when the compressor is started up; blinking in case of
delay, protection or blocked enabling.
ON when defrosting; blinking in case of manual enabling.
ON when the alarm is enabled; blinking when the alarm
is silenced.
ENGLISH
9
