SM
1.7. SV1
SV1 freezer cabinets are intended for storing and displaying ice creams and other frozen
goods. The storage temperature range is -25...-23° C.
Make sure that the cabinet version and storage temperature are correct for the products to
be stored.
WARNING
When opening SV1 cabinet doors, note that the opening mechanism is
lightened and the doors open slightly upwards. When the door is opened,
the lower corner of the door ends up further out than it would if the door was
in a normal, upright position. This may result to an unexpected collision.
Respectively, the door shuts down softly and slowly. Do not force or slam the
door - instead, let the door close by gravitational force.
Open and close the doors carefully to avoid accidents.
Instruct the customers in the safe use of the doors.
Do not attach any material, for example price tags, on the doors.
1.8. SL1
SL1 serve over and self-service display cabinets are intended for storing and displaying a wide
variety of foods and foodstuffs, including dairy products, processed meat, convenience foods,
salads, processed and semi-processed foods and packed meat. SL1 display cabinets are
available for the deep-frozen, refrigerated and warmed products.
SL1 display cabinets are supplied for a number of different storage temperature ranges. The
cabinet versions are:
• Cabinet without integrated machinery unit, 0 version, cooling provided by remote
refrigeration equipment.
• Cabinet with integrated machinery unit, M version, provided with local cooling equipment.
• Freezer cabinet, F.
The temperature range in the cabinet is -21...-18° C. The electronic thermostat and light
switch are located in the lower right corner of the cabinet on the service side. The fan
evaporator is located inside the cabinet under the service access covers.
• Heated display counter, H.
The heating equipment for the display counter is comprised of two heating units:
• A heat radiator located in the roof compartment of the cabinet. This radiator is
always switched on when the electric plug is in the wall socket and the main switch
(see figure page 3, figure B2) is turned on. No automated feature disconnects this
heating, which also provides lighting for the cabinet.
• Heating resistors are installed in the base of the storage compartment. SL1 H
display counter has five or seven resistors. The heat output of these resistors is
controlled by a thermostat (see figure page 3, figure C2). The thermostat can be
set to the temperature desired, which is generally +70° C. The maximum setting is
+90° C.
Version 04/2024
ENGLISH
4
