9) ESPLOSI-RICAMBI / LAYOUT-SPARE PARTS LIST / VUE ECLATEE-LISTE DES PIECES /
ZEICHNUNGEN-ERSATZTEILLISTE / DIAGRAMAS - RECAMBIOS
Ed. 07/20
DESCRIZIONE
ASSIEME SUPPORTO ALBERO
KIT TRASMISSIONE ITA84
ASS. MOTORE TENSIONE
O-RING OR3162 (D41)
PARAOLIO G 17X23X3
CUSCINETTO 6003/C3
CUSCINETTO A RULLI BK 1012
CUSCINETTO 7202
VITE T.C.E.I. M6x16 UNI5931
DADO M6 UNI5588
VITE S.T.E.I. M5x6 UNI5927
VITE S.T.E.I. M8x1x10 UNI5923
VITE S.T.E.I. M6x6 UNI5927
VITE S.T.E.I. M8x1x14 UNI5923
RONDELLA UNI6592 PER M10
VITE T.B.E.I. M6x16 ISO7380
DADO AUTOBLOCCANTE M10 DIN985
VITE A COLLETTO Ø12 M10x12x90 ISO7379
VITE TCEI UNI5931 M3X10
VITE TCBCR 3.9X13 6954 ZIN
VITE PT M3X5 TESTA LARGA PER PLAST.
DADO ES. M3 AUT. DIN985 BASSO
VITE TBCR BOSSARD BN13577 3.5X10 KA35
VITE K22X10 WN1452 BN13265
BOCCOLA BMC 141615
SEEGER PER INTERNI J47 U.7437 R150
RONDELLA PS 35X25X0.5
RONDELLA PS 35X25X0.2
SEEGER D15 UNI 7435
RONDELLA PS 35X25X0.1
SPINA CIL. TEMPRATA 10X60 DIN6325
SPINA CIL. TMP 4X24
PULSANTE REVERSE ITA 84-71
POTENZIOMETRO ITA 84-71
LED ITA 84-85-71
MICROSWITCH TENSIONE ITA 84-71
BATTERIA COMP. MAKITA BL 1840 18V-4A
CARICABATTERIE COMP. MAKITA 18V-4A
CARICABATTERIE ATTACO U.S.
POWER CARD ITA 84
DISTANZIALE
SUPP. ALBERO RULLO
RULLO
PERNO PER RULLINO
PIEDE
FERMASIGILLO
PERNO PER PIEDE MOBILE
RULLO DI TRASCINAMENTO
CODICE
ITEM
A000100
SHAFT SUPPORT ASSEMBLED
A000171
TRASMISSION KIT ITA84
A000233
B300130
B300132
B400108
B400109
ROLL BEARING BK1012
B400110
B500040
SCREW M6x16 UNI5931
B500052
B500107
B500142
SCREW M8x1x10 UNI5923
B500143
B500144
SCREW M8x1x14 UNI5923
B500145
B500174
SCREW M6x16 ISO7380
B500175
AUTO LOCKNUT M10 DIN985
B500176
SCREW Ø12 M10x12x90 ISO7379
B500273
B500277
B500559
B500586
B500587
B500659
B600117
GUIDE SOCKET BMC 141615
B600122
INT. SEEGER J47 U.7437 R150
B600123
WASHER PS 35X25X0.5
B600124
WASHER PS 35X25X0.2
B600346
B600390
B700151
CYL. PIN TMP 10X60 DIN6325
B700182
B800573
REVERSE BUTTON ITA 84-71
B800574
POTENTIOMETER ITA 84-71
B800575
B800578
TENSION MICROSWITCH ITA 84-71
B800580
BATTERY BL 1840 18V-4A
B800581
BATTERYCHARGER 18V-4A
B800592
BATTERYCHARGER U.S. PLUG-IN
B800594
D000870
D000890
ROLLER SHAFT SUPPORT
D000900
D000910
D000920
D000940
D000950
D000960
DESCRIPTION
ASS. TENSION MOTOR
O-RING OR3162 (D41)
STOP OIL G 17X23X3
BEARING 6003/C3
BEARING 7202
NUT M6 UNI5588
SCREW M5x6 UNI5927
SCREW M6x6 UNI5927
WASHER M10 UNI6592
SCREW M3X10
SCREW 3.9X13
SCREW M3X5
NUT ES. M3
SCREW 3.5X10
SCREW K22X10
SEEGER D15 UNI 7435
WASHER 35X25X0.1
PIN 4X24
LED ITA 84-85-71
POWER CARD ITA 84
SPACER
ROLLER
ROLLER PIN
FOOT
SEAL STOP
MOVABLE PIN FOOT
FEEDWHEEL
Q.TA'
Q.TY
1
1
1
§
1
1
2
1
1
2
1
1
1
2
1
1
1
1
1
1
7
6
1
7
2
1
1
VAR
VAR
1
VAR
1
1
1
*
1
1
1
1
1
1
1
1
1
1
§
1
1
1
1
1
§ *
