nel interference. To prevent this from happening, the
crystals in one of the radios must be changed for
another channel.
Rx-crystal

13. Ratches function of the throttle stick

When radio control systems leave the factory, all the
control sticks are set so that they automatically return
to their neutral positions (centre of stick travel) when
they are released. However, this neutral function is
not required for either the control of an electric-powe-
red aircraft's drive motor or the setting of a boat's
sails, since it would involve the pilot's having to keep
hold of the stick. The ratchet spring (Order No.
F1545) may be fitted to deactivate the neutral func-
tion.
Fitting
1. Remove the batte-
ries. Detach the
front of the case by
unscrewing the 4
screws Remove
the front cover of
the transmitter
switch.
2. remove the neutrali-
zing spring and
Instruction manual
Attack T2ER
3.
4.
5.
Tx-crystal
14. Asymmetrical stick travel adjust-
1.
2.
4.
5.
16
rocking lever from the control stick.
Fit the ratchet spring using a screw.
Re-close the case. Put the cover of the switch in
place again.Check the correct position of the
battery contacts.
Install the batteries.
swing arm
neutralizing spring
ment (30% / 70%)
Remove the bat-
teries. Open
transmitter case.
Move the chan-
ge-over switch
on the stick in
the direction of
the arrow. The
neutral position
will shift.
50%
50%
Re-close the case.Check the correct position of
the battery contacts.
Install the batteries.
Order No.
F 2210 / F2211
screw
Ratched plate
Throttle stick
Change-
over
switch
70%
30%
