Command and safety device status display mode
SAFETY DEVICE STATUS
COMMAND STATUS
AP PED
PP
CH ORO
POWER C485
BA/60 magnetic sensor or STOP/RELEASE position) are normally on. If an indicator is off, the relative device is in alarm
Turning off the "BREAK" LED is always accompanied by the "STOP" LED turning off.
TEST mode
The TEST
To activate the mode, press the TEST button with the automatic barrier system at rest. If the barrier is moving, pressing
TEST stops the barrier. Pressing the button again enables TEST mode.
Example: STOP contact in alarm state.
N.B.: If one or more contacts are open, the barrier will neither open nor close.
the next device is displayed. Any further alarm states are also displayed with the same logic.
Press the TEST button again to exit test mode.
After 10 seconds with no user input, the display returns to command and safety device state display mode.

Standby mode

POWER
COMMAND STATUS:
The command status indicators on the display (segments AP = open,
PP = step mode, CH = close, PED = partial opening, ORO=clock) are
FT
normally off. They illuminate when a command is received (e.g.:
when a step mode command is received, the segment PP illumi-
COS BREAK
nates).
SAFETY DEVICE STATUS:
The safety device status indicators on the display (segments FT =
photocells, COS = sensing edge, BREAK = BreakAway system ACS/
STOP/RELEASE
The command signal status is shown on the left hand side of the display
for 5 seconds, ONLY when the respective command signal is active (AP,
CH, PP, PE, OR).
For example, if the open command is activated, the letters AP appear on
the display.
No safety device in alarm state or barrier waiting for command.
STOP contact (N.C.) open.
Jumper the STOP contact.
Release handle or lock open.
Barrier inspection hatch open.
Sensing edge contact COS (N.C.) is open. Check connection. If
sensing edge is not installed, disable with
Photocell contact FT (N.C.) is open (message shown on MASTER
controller displayed). Check connection. If photocell is not
installed, disable with
Shatter-proof system enabled, or not connected or incorrectly con-
nected (par.
This mode is activated after 30 minutes with no user input. The POWER LED
Press UP , DOWN
.
)
, + or - to reactivate the control unit.
.
