2.2 Technical data
Weight
Required air pressure
Setting force at 0.6 MPa
Air consumption
Stroke
Height
Length
Width [over the aircoupling]
Front nozzle
Front nozzle length
2.3 Range of usage
The pneumatic blind rivet nut tool is designed for riveting with:
> Blind rivet nuts M4 – M12 [aluminium, steel, stainless steel]
> Blind rivet bolts M4 - M8 [aluminium, steel, stainless steel]
2.4 Tool operation
The manufacturer pre-equipped the tool with an anvil and mandrel for blind rivet
nuts M8. For inserting blind rivet nuts with a different dimension, it is necessary
to exchange the anvil and mandrel accordingly. Change the basic set-up and
regulation of the tool as follows:
1. Loosen the counternut of the anvil
2. Screw the anvil from the front nozzle
3. Screw the mandrel from the sleeve
4. Choose appropriate anvil and mandrel, as per the following chart:
2.0 kg
0.5 - 0.7 MPa
23 kN
1.5 L / stroke
8 mm
270 mm
262 mm
125 mm
Ø 23.8 mm
91 mm
AS-12PC
