Read This First
Thank you for selecting the ZFX Stack package/ZFX Control package.
The ZFX Stack package/ZFX Control package includes the ZFX Plug-in
which gives access to a wide range of amplifier sounds and effects, with
amazingly versatile settings. The ZFX Plug-in can of course be used on its
own, but it also works great in combination with the bundled DAW
application or other DAW applications that you may own.
This Startup Guide explains the necessary steps for installing the ZFX Plug-
in on your computer and provides basic information about how to produce
sound.
For details regarding operation, please see the PDF Manual.
Do not plug the unit into the computer until prompted to do so!
ZFX Plug-in installation
[Precautions]
• You must have Administrator privileges to install the software. If your user level does not provide this, please contact your system
administrator.
• Before starting the installation, shut down all other applications.
• When performing the installation, do NOT plug in the USB cable connecting the S2t/C5.1t to the computer before being prompted to do so.
• During the S2t/C5.1t driver installation process, you will be prompted to connect the USB cable to the computer. Connect the cable and then
do not disconnect it until the installation is completed.
• To start the ZFX Plug-in, .NET Framework 2.0 must be present on the computer. If this is not installed, a prompt will appear to confirm
installation of .NET Framework 2.0.
Insert the ZFX Plug-in installation disc into the CD-
ROM drive of the computer
The contents of the disc will be displayed automatically.
Do not connect
* If the contents of the disc are not
displayed automatically, go to My
the USB cable yet!
Computer and open the CD-ROM drive.
Double-click on the "ZFX Plug-in Setup.exe"
file to start the installation process.
I Select setup language
Select the language to use, and
click [OK].
* If .NET Framework 2.0 is not installed on the computer, a prompt
will appear to confirm installation of .NET Framework 2.0.
I Installation wizard start
Click [Next] to begin the
installation.
Start-up Guide
I End User License Agreement
The End User License Agreement is displayed. Read the
agreement and click [Next] to confirm your acceptance of the
agreement.
I Warning message
A message telling you not to connect the USB cable yet appears.
I Installation target folder
To accept the default installation target folder, click
[Next].
To select a different folder, click [Change].
* If you do not want a shortcut to be created on the
Desktop, remove the check mark from the box.
I VST plug-in folder
The installation will use this folder. Click [Next].
I Ready to Install the Program
Click [Install] to start
the installation.
I Continue with driver installation
Click [Next].
* If the driver install wizard window is not visible, click on
"ZOOM S2t C5.1t Audio Driver" in the task bar.
I License Agreement
The License
Agreement is
displayed. Read the
agreement and place a
check mark in the "I
accept the terms in the
License Agreement"
box to confirm your
acceptance of the
agreement. Then click
[Next].
I Choose Start Menu Folder
You can specify the
destination folder
where the shortcut to
uninstall/repair the
driver will be located.
Normally, simply click
[Install].
I Welcome to ZOOM Driver Setup!
A dialog box such as
shown above will appear
three times. Click [Next]
every time to proceed.
If a software installation warning dialog box is shown,
click [Continue].
If a Windows Security message indicating that the driver
software publisher cannot be verified appears, click
[Install this driver].
* In this case, the message "ZOOM S2t C5.1t Audio Driver
(Not Responding)" may appear, but this is not a problem.
I Please plug in the device now
Connect the
USB cable!
When the "PLEASE PLUG IN AUDIO DEVICE NOW" dialog
box appears, connect the unit and the computer with the
USB cable and click [Next]. After plugging in the USB cable,
do not disconnect it until the installation is completed.
When the message "Welcome to the Hardware Update Wizard"
(Windows XP) appears, select "Install the software
automatically" and click [Next] to complete the process.
When the message "Found New Hardware" (Windows Vista)
appears, select "Locate and install driver software" and click
[Continue] to complete the process.
When the Windows
search wizard has
completed, return to
"ZOOM S2t C5.1t Audio
Driver" and click [Next].
If a warning message to
confirm Hardware
installation appears, click
[CONTINUE ANYWAY].
When a dialog box such
as shown here appears,
click [Finish].
Click [Finish] to complete
the installation.
For starting up and other basic operations, turn over.
© ZOOM Corporation
Reproduction of this manual, in whole or in part, by any means, is prohibited.
ZFX-Startup-E-1.0.0.0
