Parameter zur Sonder-Funktionseinstellung der Ein/Ausgänge
Parameter related to special I/O functionality
Typ
Parameter Parametername
Out
P_141
In
P_142
In
P_143
RS232 P_144
Out
P_145
In/ES
P_147
Out 60V:
0 = no function
1 = on after booting;
2 = on, when MC enabled
Funktion Ausgang
3 = On when break after motorstop is active with 2 seconds
PORTE.5
delay
4 = on, when MC enabled and Motor <100 1/min
5 = spare
6= Motor in Stop-Position (after stepper)
0 = no function;
1 = Reset setpoint enable (Signal = 1);
2 = Remote Setpoint RS485 active (Signal = 1) ;
3 = PWM Setpoint acitve (1-2ms Pulsduration, refer to
P103/104);
Reaktion_PIN_F3
5 = Setpoint hold (positve edge)
4 = In_Button_Start alternative (MC-Enable);
7 = Sensor Stop Stepper positioning, with falling edge;
8 = Sensor Stop Stepper positioning, with rising edge;
9 = Hybrid Generator ready
10 = Reset setpoint enable (Signal = 1); charger OC6000 V2
0 = no function;
1 = Reset setpoint enable (Signal = 1);
2 = Remote Setpoint RS485 active (Signal = 1) ;
3 = PWM Setpoint acitve (1-2ms Pulsduration, refer to
P103/104);
Reaktion_PIN_F4
5 = Setpoint hold (positve edge)
4 = In_Button_Start alternative (MC-Enable);
7 = Sensor Stop Stepper positioning, with falling edge;
8 = Sensor Stop Stepper positioning, with rising edge;
9 = Hybrid Generator ready
10 = Reset setpoint enable (Signal = 1); charger OC6000 V2
RS232
0 = keine RS232 Kommunikation
Communication
1 = RS232 Kommunikation zu Torquesensor ME-Systeme
2 =
0 = no function;
1 = direction detection - on = direction forward
2= On if motor rpm in window 1< n < P025;
Funktion Ausgang
3 = RPM cam 1turn. = On, 1turn = Off
PORTR.0
4= On if motor rpm in window 1< n < (P025+350)
5= Motor running or MC_Temp > P072 or Motortemp. >45°C
6= Motor in Stop-Position (after stepper)
(Connector Emergency Stop)
0 = no reaction;
1 = normale stop with ramp down (when input 0pen);
2 = Schnellstoprampe (when input 0pen); ;
reaktion_not_stop
3 = Reglerfreigabe aus (when input 0pen); ;
11 = normaler Rampenstopp (when input closed);
12 = Schnellstoprampe (when input closed);
13 = Reglerfreigabe aus (when input closed);
Parameterfunktion
58
