HPD40/50D
Motoranschlussleitung
Wireslabels
U1 A
(M1 front)
V1 A
(M1 front)
W1 A (M1 front)
U1 B (M1 front)
V1 B (M1 front)
W1 B (M1 front)
U2 A (M2 back)
V2 A (M2 back)
W2 A (M2 back)
U2 B (M2 back)
V2 B (M2 back)
W2 B (M2 back)
Front = propeller mounting side
Back = motor mounting side
MC 1 Master
U
V
W
MC 2 Slave
Ein falsch angeschlossener Motor kann zum Schaden am Motorkontroller führen!
A wrong connected motor will damage the motorcontroller.
MC 1 Master
U
V
W
W
V
U
MC 1 Slave
MC 2 Master
U
V
W
MC 1 Slave
U
V
W
V
MC 2 Master
MC 2 Slave
U
V
W
U
V
W
W
U
26
