Installation
Counter with retro-reflective sensor (DZ2001)
Fix a prismatic reflector / reflective
tape in the desired position. Align
the counter towards the reflector
and fasten it by means of a
mounting set. The light spot must
hit the prismatic reflector.
Maximum range is only possible
with precise alignment.
Counter with diffuse reflection sensor (DZ2006)
Align the counter towards the
object to be detected and fasten
it by means of a mounting set.
Maximum range is only possible
with precise alignment.
A special mounting set is available as an accessory (order no. E80020).
Adjustment aid for laser units:
You can increase the intensity of the transmitted light so that the trans-
mitted light spot can be clearly seen.
1. Briefly press the
2. Press the
3. Briefly press the
(→ The display
increased).
You automatically return to the normal transmission power after
approx. 15s or by briefly pressing the
button 3 times (→
button until
button.
flashes and the transmitted light intensity is
is displayed).
is displayed.
button.
