Programming mode:
Select the Programming mode by
• changing to the Display mode first,
• then selecting the parameter you would like to change
• and then by pressing the
Internally the unit also remains in the operating mode. This means that
it continues to perform its functions with the existing parameters until
the change has been stored. In the display the RUN indicator is indi-
cated next to the PRG indicator. In addition the parameter abbrevia-
tion flashes in the 3-digit alphanumerical display.
• Change the parameter value with the button
• Acknowledge the setting by pressing the
eter abbreviation no longer flashes and the PRG indicator goes out.
The new value is permanently stored and effective for the counting
function.
• Terminate the Programming mode and return to the Run mode by
pressing the
for approx. 15s (timeout), the unit automatically returns to the Run
mode.
Cancel the parameter setting:
If you press the
been changed, or if no button is pressed for approx. 15s, the unit will
return to its previously set parameter values. The unit then passes into
the Display mode and indicates the old parameter value which remains
effective.
button briefly.
button for approx. 3s. When no button is pressed
button only briefly when the parameter value has
or .
button until the param-
