Electrical connection
The unit must only be connected by a skilled electrician.
The national and international regulations for the installation of
electrical equipment must be observed.
Voltage supply to EN50178, SELV, PELV.
Protect the unit from electrostatic discharge and spikes.
Disconnect the installation before the unit is connected with a socket
(8 poles).
Sockets are available as accessories:
• socket straight, 2m, 8 x 0.25mm
• socket angled, 2m, 8 x 0.25mm
Pin / wire connection:
PIN core colour
1 white
2 brown
3 green
4 yellow
5 grey
6 pink
7 blue
8
Wires without function (n. c.) must not be connected.
control input gate (counting interruption)
red
2
(order no. E80021)
2
(order no. E80022)
connection
L+ (24 V)
output 1
output 2
control input reset / preset
n. c.
L- (0 V)
n. c.
