4.2 Electrical data
Rated voltage
(see
approvals for limit values)
Rated frequency
Voltage range
Flashing light
current consumption
(1 Hz) max.
Sounder
current consumption
max.
Power consumption
5. Approvals
(Approvals are valid for marked devices)
E189090:
S7256:
Rated Voltage
Ambient
temperature
UL, cUL
115 V AC
230 V AC
24 V AC
24 V DC
Connecting cables>
PYRA Xenon beacons PY X-L(A)-15 comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules.
09/2023
Operating Instructions PY X-L-15/ PY X-LA-15
PY X-L-15
24 V AC
230 V AC 115 V AC
50/60 Hz
187 -
90 -135 V
255 V
170 mA 350 mA 970 mA
--
34.5 VA 34.5 VA
PY X-L-15
PY X-LA-15
Visual Signal Appliance - General Signaling Equipment (UEES, UEES7)
(PY X-L-15)
Audible and Visual Appliance for General Signaling (Non Fire Alarm) Use.
(UCST, UCST7 and UEES, UEES7) (PY X-LA-15)
115 V AC or
230 V AC or
24 V DC / 24 V AC
-40°C .. +66°C
Suitable for indoor and outdoor use.
Warning: Not to be used as a Visual Public Mode Alarm Notification Appliance.
(PY X-L-15)
Warning: Not to be used as an Audible and Visual Public Mode Alarm Notifica-
tion Appliance. (PY X-LA-15)
According to CSA-C22.2 No. 205-12 clause 4.3.4 the connection is limited to
max. 10 leads.
Installation:
The units shall be installed indoors or outdoors in accordance with the manufac-
turer's installation instructions as well as the National Electrical Code (NFPA 70)
in US. In Canada, they shall be installed in accordance with the Canadian Elec-
trical Code, Part 1. The installations shall also be in a manner acceptable with
the local authority having jurisdiction.
Cable gland entries:
Conduit installation needs to be UL/ cUL listed fittings suitable for knockout
openings.
24 V DC
230 V AC 115 V AC
+/-10% +/-20%
--
21.6 - 19.2 - 187 -
26.4 V 28.8 V 255 V
670 mA 170 mA
10 mA
22 VA 13 W 38 VA
Page 3 / 8
PY X-LA-15
24 V AC 24 V DC
+/-10%
50/60 Hz
21.6 -
90 -135 V
26.4 V
350 mA 970 mA 670 mA
10 mA 60 mA
36.5 VA 23 VA
086200004a
+/-20%
--
19.2 -
28.8 V
25 mA
13.5 W
