Pfannenberg PYRA Serie Betriebsanleitung Seite 11

en
3. Dimensions
M20 cutout prepared (both sides)
M20 cutout prepared
Bore pattern; view from below
4. Technical data
4.1 General
Flash energy
Flash frequency
Max. sound level
Volume control
Tones
Duty cycle
Connecting terminals
Ingress protection
Impact strength
Protection class
Operating temperature
Storage temperature
Max. rel. air humidity
Cable inlet
Sealing area of the feed-
through grommet
Housing material
Lens material
Installation position
Lens colors
09/2023
Operating Instructions PY X-L-15/ PY X-LA-15
PY X-L-15
*
- max. M6 screw, tightening torque 5Nm
PY X-L-15
15 J
-
-
-
0.14 – 2.5mm² fine stranded / AWG24 - AWG 14 (stranded)
-40°C...+55°C (UL Certification see page 3)
A cable gland with a sufficient degree of protection must be provided
when cable diameters of < 7 mm are used
transparent, white, yellow, amber, red, green, blue
Bore pattern; view from below
0.1 / 0.5 / 0.75 / 1 Hz
100%
IP 66 (EN 60529), Type 4 & 4x
IK 08 (EN50102)
II double insulated equipment
-40°C...+70°C
90%
4x M20 pre-embossed
7 – 13 mm
PC/ ABS Blend
PC
any
Page 2 / 8
PY X-LA-15
M20 cutout prepared (both sides)
PY X-LA-15
15 J
103 dB (A) @1m
max. - 25 dB
8
086200004a
