Assembly and installation
Connecting the sensor to measuring modules
Connect the ICT 8 sensor for inductive conductivity to the mA/mA or mV/mA module of a
DACb or AEGIS II controller.
Tab. 3: AA module terminals for channel 1 and channel 2, VA module terminals for channel 2
Measuring range
2 mS/cm
20 mS/cm
200 mS/cm
10
GND terminal
Brown + Black
Black
Orange + Black
IN terminal
Green
Green
Green
V+ terminal
Yellow + Red
Yellow + Red
Yellow + Red
