Calling Programs
9.2 Calling Scenes
1
Press the CHASE button (button lights).
2
Call the desired chase with the number buttons at
the lower right corner (button lights).
ï
If necessary, use the PAGE button to switch
between the memory banks 1-15 (LED A lights)
and 16-30 (LED B lights).
ï
Up to 5 chases can be selected simultaneously.
The chases are played one after the other. The
LED of the chase currently playing flashes, the
others light.
ï
The display indicates the number of the chase
(e.g. <Chase01=) in the lower line and the current
step (e.g. <Step001).
3
Select the chase running mode with the button
RUN MODE. The mode is indicated by the LEDs
above to the button. See the table at the right-hand
side for a description of the modes.
4
A flashing LED indicates which chase can be
adjusted when several chases are selected
simultaneously. The chase selected last can be
adjusted. To adjust a different chase instead, keep
the corresponding number button pressed until its
LED flashes.
5
To stop a chase, press the corresponding number
button so that its LED extinguishes.
www.eurolite.de
Overview of running modes
MANUAL:
The chase can be manually advanced step by step
with the PAN/TILT wheel. The PAN/TILT button must
be engaged for this function (SPEED LED lights).
MUSIC:
The individual steps of the chase run to the rhythm of
the music picked up via the internal microphone. The
sensitivity of the sound control is adjustable. For this,
keep the RUN MODE button pressed and turn the
PAN/TILT wheel to adjust a value between 0-100 %.
The higher the value, the higher the sensitivity.
AUTO:
The individual steps of the chase run at the adjusted
speed and fade time. The PAN/TILT button must be
engaged for this function (SPEED LED lights).
Use the PAN wheel to adjust the running speed, i.e.
how long a scene is shown, between 10 minutes and
0.1 seconds (indication <Wait<). Alternatively, you can
press the MENU/ESC button twice (tap function). The
time between the two actuations of the button defines
the time until the next change of scene. The display
shortly inserts the setting, e.g. <Speed 5.5S<.
Use the TILT wheel to adjust the fade time, i.e. the
time between the steps, between 0 and 30 (indication
<Fade<). The time adjusted is will be taken over in
manual and sound-controlled mode.
56
