Patching and Managing Devices
6.6 Step 6: Invert Output Values
It is possible to individually invert the output values of the 512 control channels. During active inversion the fader displays
the maximum DMX value when it is drawn down and the value of zero when it is at the top. Use this function if, for
example, some spotlights show the shutter channel at zero when open, but is open at 255 with others. In this way,
differences in the functioning of individual spots are compensated on the console, so that all devices respond
homogeneously.
1
Select the option <FADER REVERSE= with the SWAP button. The display indicates the control element in the
upper line, e.g. <FADER:1/R< and the current setting in the lower line, e.g. <REVERSE:NO<.
2
Adjust the desired control element with the PAN wheel and use the TILT wheel to select the setting [YES] if the
output value of the control channel is to be inverted or [NO] if not.
3
Press the ENTER button to memorize your setting. All LEDs of the controller flash three times to confirm.
4
Repeat the steps to invert further control channels.
6.7 Step 7: Assign the Fade In Function
Each device with color mixture can be individually assigned to produce either color fade or quick color changes in the
execution of programs.
1
Select the option <COLOR FADE< with the SWAP button.
2
Use the PAN wheel to select the setting [YES] if fade in of the device should be possible or [NO] if not. With the
function activated, the controller automatically creates all necessary intermediate values for the fade in.
3
Press the ENTER button to memorize your setting. All LEDs of the controller flash three times to confirm.
4
Repeat the steps to configure further fixtures.
