System Settings
11.7 Data import [Data load]
1
Connect a USB memory device to the controller9s
USB port.
ï
The files to be imported must be stored in the
folder <DMX MOVE CONTROLLER 512 PRO<
located on the root directory of the USB memory
device.
2
Call the menu item [Data load].
ï
The display indicates <Press number key Select
file< (select file with number button).
ï
The LED of a number button lights, when data is
available on the USB memory device for this
memory bank.
3
Select the file to be loaded with the number
buttons at the lower right corner.
ï
The display indicates a progress bar.
4
After successful completion of the data import, the
device returns to the main menu level. Repeat the
steps 2 and 3 to import further files.
11.8 Blackout Function [Black-out
mode]
It is possible to define whether all control channels react
on the button BLACKOUT or only the dimmer control
channel.
1
Call the menu item [Black-out].
2
Use the PAN wheel to choose between the
settings [All channels] and [Only dimmer].
ï
All channels: All control channels react on the
button (i.e. in the blackout state the control
channels have the value zero).
ï
Only dimmer: Only the dimmer control channel
reacts on the BLACKOUT button (i.e. in the
blackout state the control channel has the value
zero).
3
Confirm your setting with ENTER.
ï
The display shortly indicates <SAVE OK< and
returns to the main menu level.
www.eurolite.de
11.9 Fog Machine [Fog machine
control]
The controller can operate a DMX fog machine. This
menu allows adjusting the machine.
1
Call the menu item [Fog machine control].
2
Use the PAN wheel to choose between the
settings Auto FOG [OFF] and Auto FOG [ON].
ï
Auto FOG [OFF]: By pressing the DMX FOG
MACHINE button, the fog machine is activated.
ï
Auto FOG [ON]: The fog machine is activated by
the built-in timer. The time intervals and duration
are adjustable.
3
Press the SWAP button to adjust the timer
functions.
4
Use the PAN and TILT wheel to adjust the
duration and the time intervals (i.e. the time
between the individual fog outputs) between 1 and
600 seconds.
EXAMPLE
emit fog for 3 seconds every 60 seconds, adjust
the [ON TIME] to 3 seconds and the [OFF TIME] to
60 seconds. For a hazer, which is supposed to
emit fog continuously, adjust an [ON TIME] of 600
seconds and an [OFF TIME] of 1 second.
5
Press the SWAP button. Then use the PAN wheel
to enter the DMX address for the fog machine9s
first control channel and the TILT wheel to enter
the DMX value.
6
Press the SWAP button once again to set up a
second control channel.
7
Confirm your settings with ENTER.
ï
To confirm the memory procedure, all LEDs of the
controller flash three times.
8
After completing the settings, press ESC to return
to the main menu level.
61
