Operating Elements and Connections
No.
Element
1
Motorized faders
2
FIXTURE buttons
3
PAGE button
4
PAN/TILT button
5
PAGE UP/CLEAR button
6
PAGE DOWN/HSV button
7
Master fader
8
Display
9
PAN encoder wheel
10
TILT encoder wheel
11
REC/ENTER button
12
MENU/ESC button
13
BLACKOUT/DEL button
14
RUN MODE/SWAP button
15
MOVEMENT button
www.eurolite.de
Function
For adjusting the DMX values of the connected light effect units. The
current DMX value is indicated in the display. The faders are split into 4
pages so that 4 x 8 DMX channels and both movement channels can be
controlled (i.e. up to 34 DMX channels per fixture).
To select and deselect up to 24 devices on three pages. The buttons light
to indicate which devices are selected.
To switch the FIXTURE buttons (2) between the three fixture pages.
" LED A lights: page A is selected (fixtures 1-8).
" LED B lights: page B is selected (fixtures 9-16).
" LED C lights: page C is selected (fixtures 17-24).
" LED off: The PAN/TILT wheels control the pan/tilt channels
" LED on: The PAN/TILT wheels control the special features such as
movements.
" To switch the faders (1) between the four pages. Each time the button is
pressed, the controller will advance one page. The LEDs above the
button indicate which page is selected.
" Keep this button pressed for 3 seconds to set all adjustments made
through the faders and encoder wheels to zero.
" To switch the faders (1) between the four pages. Each time the button is
pressed, the controller will go back one page. The LEDs above the button
indicate which page is selected.
" Keep this button pressed for 3 seconds to activate the HSV function for
the faders 6 to 8. Then the RGB colors can be adjusted via HSV. The H
fader sets the hue, the S fader the saturation and the V fader the
brightness (value). The HSV function can be used for all fixtures for which
the RGB channels have been correctly assigned to the control elements
of the DMX MOVE PRO.
To adjust the brightness. This fader controls all dimmer channels and color
channels simultaneously.
" SPEED LED (4) off: To adjust the horizontal position.
" SPEED LED (4) on: To adjust special features such as movements.
" SPEED LED (4) off: To adjust the vertical position.
" SPEED LED (4) on: To adjust special features such as movements.
In program mode, this button activates the store command. In system
setting mode, this button confirms adjustments.
" Long actuation: To call and exit the system settings.
" Short actuation: To abort a setting procedure and jumping back to a
higher menu level.
" For inserting a scene into a chase.
" To adjust the running speed for a chase in time-controlled mode (tap
function).
" Live mode: Turns off all fixtures or sets all control channels to the value
zero ( system settings).
" Program mode: For deleting scenes or chases keep this button pressed
and select the memory bank to be deleted with the number buttons (20).
" Live mode: For setting the running mode of a chase. A short actuation
switches between manual, sound-controlled and automatic mode. The
LEDs next to the button indicate the current setting.
- MANUAL: The chase can be manually advanced step by step with the
pan wheel.
- MUSIC: The individual steps of the chase run to the rhythm of the music
picked up via the internal microphone.
- AUTO: The individual steps of the chase run at the adjusted speed and
fade time.
" FX mode: For switching between the parameters.
When this button is activated (LED lights), the number buttons (20) activate
movements or color effects.
43
