Operating Elements and Connections
No.
Element
16
CHASE button
17
SCENE button
18
PAGE button
19
DMX FOG MACHINE button
20
Number buttons 1 to 15
21
USB port
22
Power on/off
23
Power input
24
Fuse
25
Microphone for sound control
26
DMX512 output
www.eurolite.de
Function
When this button is activated (LED lights), the number buttons (20) store
and activate chases.
When this button is activated (LED lights), the number buttons (20) store
and activate scenes.
To switch the number buttons (20) between the two memory pages in
CHASE or SCENE mode.
" LED A lights: page A (memory location 1-15) is selected.
" LED B lights: page B (memory location 16-30) is selected.
To activate a connected fog machine.
These buttons control different functions depending on the selected mode
and have a dual occupancy; the button PAGE (18) allows switching
between the two memory pages in CHASE or SCENE mode.
" MOVEMENT: To activate and deactivate movements (button 1-9) or color
effects (button 10-15).
" CHASE: To store and activate chases.
" SCENE: To store and activate scenes.
For connecting a USB flash drive for storing and importing data and
firmware updates.
Switches the controller on and off.
Plug in the mains cable here.
Only replace the fuse when the device is disconnected from mains. Only
use fuses of the same rating and power. The correct fuse value is specified
on the rear panel.
3-pin XLR jack for connecting the DMX input of the first light effect unit.
44
