System Settings
11.5 RDM DMX Address Assignments
[RDM DMX Address setup]
This menu allows identifying connected RDM devices
and changing their DMX address assignment.
1
Call the menu item [RDM DMX Address setup].
2
Select the setting [YES] with the PAN wheel to
access RDM functions and confirm with ENTER.
3
The controller starts searching for RDM devices.
The
display
indicates
COUNT005< when five devices have been found.
4
Select the desired device with the PAN wheel. The
display indicates information regarding the device
in the upper line and the corresponding DMX
address in the lower line.
5
Use the TILT wheel to change the DMX address
and confirm with ENTER.
ï
Any settings changed will be instantly accepted by
the unit.
6
Press the SWAP button to indicate the UID
(manufacturer ID and serial number) of the device
in the upper line of the display.
7
Press the BLACKOUT button to perform the
identify function for the device. The device will
send a status response so that it can be properly
identified even if there are multiple identical
spotlights.
8
After your settings, return to the main menu level
with ESC
REGARDING RDM
.
" RDM stands for "Remote Device Management" and
makes remote control of devices connected to the
DMX bus possible. RDM is an extension of the
DMX512 protocol. RDM is especially useful when the
device is installed in a remote area.
" RDM is integrated in DMX without influencing the
connections. RDM data is transmitted via the
standard XLR pins 1 and 2 and does not require a
new cable type. RDM-ready and conventional DMX
devices can be operated in one DMX line. If DMX
splitters are used, they must support RDM.
www.eurolite.de
e.g.
<DISCOVER
60
11.6 Data Backup [Data backup]
All settings of a light show, i.e. DMX settings, illumination
scenes and chases can be stored on a USB memory
device and recalled later. 15 memory banks are
available.
1
Connect a USB memory device to the controller9s
USB port.
2
Call the menu item [Data backup].
3
Select the setting [YES] with the PAN wheel and
confirm with ENTER. The display indicates <Press
number key Select file< (select memory bank with
number button).
4
Select a memory bank with one of the number
buttons at the lower right corner. The display
indicates e.g. <FILE:1< and a progress bar.
ï
Each memory bank must be stored separately. If
the LED of a number button lights, this memory
bank has been stored on the USB memory device
before.
ï
The data will be stored in the folder <DMX MOVE
CONTROLLER 512 PRO< located on the root
directory of the USB memory device. A file with the
extension <PRO= will be created for each memory
bank. You should not make any changes to the
default folder. Otherwise the controller cannot the
reload the data later.
5
After completing the data backup, the device
returns to the main menu level.
REGARDING USB MEMORY DEVICES
" This unit supports data carriers with the file system
FAT32 and with a capacity up to 32 GB.
" Prior to connecting a USB memory device, call the
system settings.
" If a data carrier is not recognized at the first try, turn
the controller off and on again.
.
