System Settings
11
SYSTEM SETTINGS
This mode allows you to change important system
settings for the controller.
11.1 Calling the System Settings
1
Keep the button MENU for 3 seconds to call the
system settings.
ï
The display indicates the first menu item <01.Patch
fixture=.
2
Turn the PAN wheel to browse the menu items.
3
Press the ENTER button to select the desired
menu item.
4
Turn the PAN wheel to change a setting and
confirm with ENTER.
5
Shortly press the ESC button to abort the setting
procedure and return to the main menu level.
6
To save your settings and exit the system settings,
keep the MENU button pressed for 3 seconds.
The following adjustments are possible:
Display
01. Patch fixture
02. Reset factory
03. Delete all Fixture patch
04. Fade mode
05. RDM DMX Address
setup
06. Data backup
07. Data load
08. Send fixture Update file
09. Black-out mode
10. Fog machine
#1
This menu item is covered in chapter 6.
#2
This function is not available.
www.eurolite.de
Function
#1
DMX configuration
Reset to factory settings
Delete all DMX assignments
Fade function
RDM DMX address
assignments
Data backup
Data import
#2
Firmware update
Blackout function
Fog machine
11.2 Reset to Factory Settings
[Reset factory]
It is possible to reset the controller to factory setting. All
programs and fixture patches will be deleted.
1
Call the menu item [Reset factory].
2
Select the setting [YES] with the PAN wheel and
confirm with ENTER.
ï
The display shortly indicates =Reset factory Please
wait Y.< and then <OK< as soon as the factory
settings are loaded.
11.3 Delete all DMX assignments
[Delete all Fixture patch]
All address assignments and control channel options
made can be deleted and reset to the presettings.
1
Call the menu item [Delete all Fixture patch].
2
Select the setting [YES] with the PAN wheel if a
reset is to be made. Confirm with ENTER.
ï
The display shortly indicates <SAVE OK< and
returns to the main menu level.
11.4 Fade Function [Fade mode]
This menu allows adjusting the fade function for the
individual steps of the chases. It is possible to define
whether only the movements will be faded or all
functions.
1
Call the menu item [Fade mode].
2
Use the PAN wheel to select the setting [ALL
CHANNELS] if the fade function is possible for all
control channels or select [ONLY PAN/TILT] if it is
only possible for the pan and tilt wheels. Confirm
with ENTER.
ï
The display shortly indicates <SAVE OK< and
returns to the main menu level.
59
