8) ELECTRICAL CONNECTION

IMPORTANT!
The appliance must be installed following the
manufacturer's instructions. The manufacturer
will not be liable for injury to persons or animals
or property damage caused by an incorrect in-
stallation.
The electrical connections of the appliance must
be carried out in compliance with the provisions
and standards in force.
Before connecting the appliance, check that:
- The voltage matches the value shown on the spe-
cifi cation plate and the section of the wires of the
electrical system can support the load, which is also
indicated on the specifi cation plate.
- The electrical capacity of the mains supply and
current sockets suit the maximum power rating of
the appliance (consult the data label applied to the
underside of the cooktop).
- The socket or system has an effi cient earth con-
nection in compliance with the provisions and
standards in force. The manufacturer declines all
responsibility for failing to comply with these provi-
sions.
When the appliance is connected to the electri-
city main by a socket:
- Fit a standard plug suited to the load indicated on
the data label to the cable.
- Fit the wires following fi gure 11, taking care of re-
specting the following correspondences:
letter L (live) = brown wire;
letter N (neutral) = blue wire;
earth symbol = green - yellow wire.
- The power supply cable must be positioned so that
no part of it is able to reach an temperature of 90 °C.
- Never use reductions, adapters of shunts for con-
nection since these could create false contacts and
lead to dangerous overheating.
Before performing any regulation, disconnect
the electricity supply to the appliance.
After carrying out any regulation or pre-regula-
tion operations, any seals must be replaced by
the technician.
The regulation of primary air to our burners is
not necessary.
32
INSTALLATION
When the appliance is connected straight to the
electricity main:
- Install an omnipolar circuit-breaker between the
appliance and the electricity main. This circuit-bre-
aker should be sized according to the load rating of
the appliance and possess a minimum 3 mm gap
between its contacts.
- Remember that the earth wire must not be inter-
rupted by the circuit-breaker.
- The electrical connection may also be protected
by a high sensitivity diff erential circuit- breaker.
You are strongly advised to fi x the relative yel-
low-green earth wire to an effi cient earthing system.
Before performing any service on the electrical part
of the appliance, it must absolutely be disconnected
from the electrical network.
If the installation requires modifi cations to the
home's electrical system or if the socket is in-
compatible with the appliance's plug, have
changes or replacements performed by pro-
fessionally-qualifi ed person. In particular, this
person must also make sure that the section of
the wires of the socket is suitable for the power
absorbed by the appliance.
WARNINGS:
all our products are conform with the
European Norms and relative amendments.
The product is therefore conform with the
requirements of the European Directivesin
force relating to:
- compatibility electromagnetic (EMC);
- electrical security (LVD);
- restriction of use of certain hazardous sub-
stances (RoHS);
- EcoDesign (ERP).
In case of failure or cut in the cable, please
move away from the cable and do not touch it.
Moreover the device must be unplugged and not
switched on. Call the nearest authorized service
center to fi x the problem.
REGULATION
9) VALVES
Regulation of the "Minimum":
- Remove knob "M" (fi g. 12 and 12/A) of the tap,
which is simply pressed on to its rod. The by-pass
for minimal rate regulation can be: beside the tap
(fi g. 12) or inside the shaft. In any case, to access
to regulation, it can be done trought the insertion of
