WARNING
• Do not use the handling bar (3) to lift up the high-pressure cleaner.
5.2 Preliminary Procedures
• Unroll the high-pressure pipe (23) completely.
• Attach a supply pipe to the water inlet's quick connection (12) using a normal garden connector. Step E -
Fig. 3.
• Open the tap to the water supply and make sure that there are no drips. Step F - Fig. 3.
• Make sure that the main switch (2) is in the off position (the "0" position) and put the plug into the electric
current outlet. Step G - Fig. 3.
• Push the main switch (2) to position "1".
• Press the cleaner gun's control lever (26) and wait for a continuous jet of water to be issued.
• Put the main switch (2) to position "0" and connect up the lance hose (28) and the spray gun (14), securing
it tightly. Step B in Fig. 3.
5.3 Standard Operation (high pressure)
• Restart the high pressure cleaner by turning the main switch (2) to position "1".
Note: during this restart phase, the high pressure cleaner will immediately stop operating after the initial
peak, as the Total Stop device will take effect.
• Use the cleaner gun's lever (26) to start operation of the high pressure cleaner and thus start cleaning.
• You can alter the angle of the jet by adjusting the head (27) (Fig. 4 - Positions a and b).
5.4 Use with Detergents
WARNING
• The high pressure cleaner was designed to be used with the detergents recommended by the Manufacturer.
Use of other detergents or chemicals can affect the safety of the high pressure cleaner.
Never suck up liquids, which contain solvents, petrol, diluents, acetone and fuel oil, as these products are
highly inflammable, explosive and toxic when nebulized.
• Carefully read the instructions and warnings on the label of the detergent to be used.
• Store detergents in a safe place out of children's reach.
• Should detergent come into contact with your eyes, wash immediately with water. Contact a doctor without
delay and remember to take the container of detergent with you.
• If detergent is swallowed, do not provoke vomiting. Contact a doctor without delay and remember to take
the container of detergent with you.
The recommended detergents, are over 90% biodegradable.
For information on how to use the detergents, refer to the instructions in the table below and on the label
on the container of detergent.
• Fill the bottle (21) with the desired detergent
• Regulate the detergent suction capacity in the following way:
- disconnect the rod (20) from the lance (19);
- the L tooth on the rod (20) must match with one of the numbers on the inside of the lance (19)
(1: minimum suction, 6: maximum suction);
- re-connect the rod (20) in the lance (19).
• Insert the bottle (21) in the foam lance (19).
• Put the main switch (2) to position "0" and connect up the lance (19) and the spray gun (14).
• Start up the high pressure again, by putting the main switch (2) to position "1" and operating its lever (26)
(suction and mixing will start automatically when water goes through).
5.5 Interrupting Use (Total Stop)
Release the lever (26) on the cleaner gun and the water cleaner will automatically stop.
The water cleaner starts operating normally again when the lever on the cleaner gun is pressed again.
WARNING
• It is important to remember that the high pressure cleaner is still operational when it is in Total Stop mode.
EN
25
